Specifications
Brand Name :
LTMG
Model Number :
FD80
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1/unit
Price :
negotiable
Supply Ability :
700 Set/Sets per Month
Delivery Time :
30days
Packaging Details :
nude packing
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Warranty :
1 year or 2000 working hours
Item :
8 ton fork lift truck
Engine :
ISUZU 6BG1
Number of cylinders :
6
Wheelbase :
2400mm
Brand :
LTMG
Model :
FD80
Max. lifting height :
8000kg
Description

chinese automatic transmission 8 ton fork lift truck with 600mm load center , pnenumatic tire

Features of 8 ton fork lift truck

1. A larger underground clearance of the chassis may overcome many kinds of complex terrain working.
2. The off-road mobility is enhanced through by driver wheels with the MPT multi-function tires, wide base and cross-country tread pattern.
3. Uses the integral-type combination instruments, the fuse box places in left side of the steering wheel, which advantage for the replacement, also installed with a cigar lighter.
4. A yellow caution light .Outlay air filter and inside air filter increase the purification performance greatly
5. Apoting Yuchai Engine ensure the powerful performance
6. Adjustable damping seat with safety belt

The specifications of chinese automatic transmission 8 ton fork lift truck with 600mm load center , pnenumatic tire

Features Manufacturer 　 　 LTMG
Model 　 　 FD80T
Power unit 　 　 Diesel
Operator type 　 　 Driver/seat
Wheel Front/rear 　 4/2
Dimension Free lift 　 mm 205
Fork size L*W*T mm 1220*170*75
Tilt range Mast forward/backward deg 6/12
Overall length(without fork) 　 mm 3740
Total width 　 mm 1995
Mast height (fork lowering) 　 mm 2620
Overall height fork raised With backrest mm 4540
Height to head guard 　 mm 2450
Turning raduis(outside) 　 mm 3550
Front face of fork to front axle 　 mm 620
Min. right angle stacking aisle pallet size :1100×1100 add clearence mm 5770
Performance Speed Max Travelling full/no load km/h 26/30
Lifting full/no load mm/s 450/550
Lowering full/no load mm/s 450/500
Max.drawbar pull full/no load kg 5300/2150
Gradeability at 1.6km/h full load % 24
Max. Gradeability full/no load % 26/22
Weight Truck weight 　 kg 10450
Weight distribution Full load front/rear kg 16370/2080
No load front/rear kg 4060/6390
Frame Tires Number front/rear 4/2
Model front axle 8.25x15-14PR
rear axle 8.25x15-14PR
Tread Front/rear mm 1470/1700
Ground clearence At lowest point(mast) mm 190
Frame mm 230
Brake Service brake 　 power bake
Parking brake 　 Mechanical-hand lever
Engine Battery Voltage/capacity V/AH 2x12V-80AH
　 Rated power kw/rpm 82.3/2000
Rated torque N-m/rpm 418/1500
Displacement L 6.494
Fuel tank capacity L 140
Transmission shift stage(front/rear-type) 　 2-2 automatic
Operating pressure Hydraulic system pressure kg/cm² 200

8 ton fork lift truck

FD80 Model Counterbalance Forklift Truck 8 Ton Forklift 600mm Load CenterFD80 Model Counterbalance Forklift Truck 8 Ton Forklift 600mm Load Center

After-sale service
Nowadays we have been sell more than 100 countries. All the products of LTMG supplied withone year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
Detail clauses and policies please see to our website and product's quality certificate.

Our company

FD80 Model Counterbalance Forklift Truck 8 Ton Forklift 600mm Load Center

FAQ

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
