EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine
Specifications
Brand Name :
LTMG
Model Number :
FG25
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1/unit
Price :
negotiable
Supply Ability :
500 Set/Sets per Month
Delivery Time :
30days
Packaging Details :
nude packing
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Power unit :
Gasoline/LPG
Tire type :
Pnenumatic
Fork size :
1070mm*122mm*40mm
Warranty :
1 year or 2000 working hours
Manufacturer :
LTMG
Engine :
NissanK25
Max. lifting height :
3000mm
Load center :
500mm
Description

2020 New brand EPA approval 2.5 ton LPG gasoline forklift truck with NissanK25 engine

Features of 2.5 ton LPG gasoline forklift truck
Ergonomically design
• Wide-view Mast and Container Mast for Choice
• Fully Integrated Frame and Suspension Chassis
• Excellent Cooling System and Heat Releasing System
• Easy to maintain and repair
• Lower Gravity
• Emergency Stop Switch
• Multiple Option Available for Choice
• LTMG Counterbalanced Diesel Forklift provide you with multiple choice as per your real need,we have different reliable engines for choice.All these engine have been tested that they can be trusted through all kinds of tough working condition and get recognition from millions of client across the worldwide.
• These engines are specifically designed for the forklift use,with low fuel consumption,less noise and vibration,all these features improve the whole performance of the forklift.

The specifications of 2018 New brand EPA approval 2.5 ton LPG gasoline forklift truck with NissanK25 engine

　 Model 　 Power shift T/M FG25
Load capacity 　 kg 2500
Operator type 　 　 Driver/seat
Wheel Front/rear 　 2/2
Dimension Free lift 　 mm 160
Tilt range Mast forward/backward deg 6/12
Overall length(without fork) 　 mm 2530
Total width 　 mm 1150
Mast height (fork lowering) 　 mm 1995
Overall height fork raised With backrest mm 4030
Height to head guard 　 mm 2120
Turning raduis(outside) 　 mm 2240
Front face of fork to front axle 　 mm 450
Min. right angle stacking aisle without load length&clearence mm 2690
Performance Speed Max Travelling full/no load km/h 17/19
Lifting mm/s 550/580
full/no load
Lowering mm/s 450/550
full/no load
Max.drawbar pull Power shift T/M full/no load kg 1650/830
Gradeability at 1.6km/h Power shift T/M % 22/18
full/no load
Weight Truck weight 　 kg 3580
Weight distribution Full load front/rear kg 5370/710
No load front/rear kg 1390/2190
Frame Tires Number front/rear 2/2
Model front axle 7.00-12-12PR
rear axle 6.00-9-10PR
Wheelbase 　 mm 1600
Tread Front/rear mm 970/970
Ground clearence At lowest point(mast) mm 110
Frame mm 115
Brake Service brake 　 Hydraulic-foot pedal
Parking brake 　 Mechanical-hand lever
Engine Battery Voltage/capacity V/AH 12/60
　 Rated power PS(kw/rpm) 47/2250(34.6/2250)
Rated torque kg-m max.(N.m) 15.7/1600(153/1600)
Number of cylinders 　 4
Placement L 2.065
Fuel tank capacity L 70
Transmission Speed forward/backward Power shift T/M 1-1 power shift T/M
Operating pressure Hydraulic system pressure kg/cm² 180


2.5 ton LPG gasoline forklift truck
EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 EngineEPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine

After-sale service
Nowadays we have been sell more than 100 countries. All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
Detail clauses and policies please see to our website and product's quality certificate.

Our company

EPA Approval 2.5 Ton Pallet Forklift Trucks Enclosed With NissanK25 Engine

FAQ
1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
