FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine
Specifications
Brand Name :
LTMG
Model Number :
FD50
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1/unit
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
500 Set/Sets per Month
Delivery Time :
30days
Packaging Details :
nude packing
Warranty :
1 year or 2000 working hours
Product name :
FD50 5 ton diesel forklift machine with original imported Japan Isuzu engine and cab
Engine :
Isuzu engine
Max.Gradeability :
20%
Service weight :
6900kg
Lift Height :
3000mm
Power Type :
Diesel
Fork Size :
1070mm*150mm*50mm
Description

FD50 5 ton diesel forklift machine with original imported Japan Mitsubishi engine and cab

Features of 5 ton diesel forklift machine
Mast option: 2 stage mast lifting height from 3000mm to 6000mm; 3 stage full free mast lifting height from 3000mm to 6000mm
Tyre option: Pneumatic tyres, Sollid tyres, Double front tyres, Non-marking solid tyres
Advantages:
1, One-piece designed of suspension frame.
2, New water tank & cooling system.
3, Larger operation space. Optimized steering wheel, operating handle and pedals.
4, High-efficency hydraulic system, lower fuel comsumption.
5, Enhanced wide view mast improves the work efficency and operating safety.

The specifications of FD50 5 ton diesel forklift machine with original imported Japan Isuzu engine and cab

GeneralModel　FD50T
Rated Capacitykg5000
Load Centremm500
Characteristic&DimensionMast Tilt AngleF/RDeg6°/12°
Front Overhang (Wheel center to fork face)mm570
Ground Clearance(Bottom of mast)mm210
Overall DimensionLength to face of fork(Without fork)mm3220
Overall Widthmm1480
Mast Lowered Heightmm2350
Mast Extended Height(With backrest)mm4250
Overhead Guard Heightmm2320
Turning Radius (outside)mm2940
　Min. intersecting aislemm2960
PerformanceSpeedTravel (Full load)km/h25
Lifting(Full load)mm/s440
ChassisTireFrontmm300-15-18PR
Rearmm7.00-12-12PR
Wheelbasemm2100
Power&TransmissionBatteryVoltage/CapacityV/Ah(12V/80Ah)x2
EngineModel　S6S
Manufacture　Mitsubishi
Rated output/r.p.m.kw57/2200
Rated torque/r.p.m.N·m284-297/1400-1600
No.of Cylinder　4
Bore×Strokemm108×125
Displacementcc4578
Fuel Tank CapacityL105
TransmissionType　Power shift
StageFWD/RVS　2/1
Operating Pressure for AttachmentMpa

17.5


5 ton diesel forklift machine
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi EngineFD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine

After-sale service
Nowadays we have been sell more than 100 countries. All the products of LTMG supplied withone year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
Detail clauses and policies please see to our website and product's quality certificate.

Our company
FD50 5 Ton Counterbalance Forklift Truck With Original Imported Japan Mitsubishi Engine

FAQ:
1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.
2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.
3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.
4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.
5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.
6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
