2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours
Specifications
Brand Name :
LTMG
Model Number :
FD100
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
25days
Packaging Details :
nude packing, fix in container
Truck weight: :
12450kg
Fork size: :
1520*175*75
Power Souce :
Diesel Engine
lifting height :
3m
attachments :
paper roll clamp ,bale clamp, rotating clamp
warranty :
1 year or 2000 working hours
mast :
two or three mast
optional :
side shift ,solid tire,
Description

fork lift truck machine 10 ton diesel container forklift with 3m lifting height

10 ton forklift Feature

Forklifts are widely used in port, railway station, airport, freight yard, factory workshop, warehouse, distribution center and distribution center. Handling, loading and unloading of pallet goods in cabins, cars and containers are essential for pallet transportation and container

transportation. device

Load Capacity:

1) the higher you are lifting a load the lower the capacity will become.

2) if you add an attachment this will also effect the unit's capacity.

3) Non-standard over sized goods will cause load centre move forward to effect capacity.

Lift Height & Collapsed Height:

besides how high you want to lift up your material, you also need to pay attention to forklift collapsed height for reasons: low doors you need to passby, ceillings in the building you are working, ceillings in the trucks you are loading/unloading.

Environment:

1) depending on enviroment in door or outdoor: diesel, gas/LPG or battery forklift

2) ground in good condition or with stones or scraps everywhere: what types of tire is proper, air tires, solid tires or no-marking tires?

3) special environment: cold storage etc

Application:

whether or not an attachment needs for working.

Others:

Do I need to stack goods in narrow warehouse? right-angle stack aisle width

Do I need a pressure regulator valve when forklift reserved with 3rd or 4th valve for attachments?

The specification of 10 ton forklift

Features 1 Manufacturer 　 　 LTMG
2 Model 　 　 FD100
3 Load capacity 　 kg 10000
4 Load center 　 mm 600
5 Power unit 　 　 Diesel
6 Operator type 　 　 Driver/seat
7 Tire type 　 　 Pneumatic
8 Wheel Front/rear 　 4/2
Dimension 9 Max. lifting height 　 mm 3000
10 Free lift 　 mm 205
11 Fork size L*W*T mm 1220*175*75
12 Tilt range Mast forward/backward deg 6/12
13 Overall length(without fork) 　 mm 4255
14 Total width 　 mm 2245
15 Mast height (fork lowering) 　 mm 2850
16 Overall height fork raised With backrest mm 4330
17 Height to head guard 　 mm 2560
18 Turning raduis(outside) 　 mm 3900
19 Front face of fork to front axle 　 mm 710
20 Min. right angle stacking aisle pallet size :1100×1100 add clearence mm 6250
Performance 21 Speed Max Travelling full/no load km/h 24/30
22 Lifting full/no load mm/s 390/410
23 Lowering full/no load mm/s 470/340
24 Max.drawbar pull full/no load kg 5850/3200
25 Gradeability at 1.6km/h full load % 22
　 Max. Gradeability full/no load % 24/20
Weight 26 Truck weight 　 kg 12450
27 Weight distribution Full load front/rear kg 20160/2290
28 No load front/rear kg 5480/6970
Frame 29 Tires Number front/rear 4/2
30 Model front axle 9.00x20-14PR
31 rear axle 9.00x20-14PR
32 Wheelbase 　 mm 2800
33 Tread Front/rear mm 1600/1700
34 Ground clearence At lowest point(mast) mm 245
Frame mm 320
35 Brake Service brake 　 power brake
Parking brake 　 Mechanical-hand lever
Engine 36 Battery Voltage/capacity V/AH 2x12V-80AH
37 Engine Model 　 ISUZU 6BG1
Rated power kw/rpm 82.3/2000
Rated torque N-m/rpm 418/1500
Number of cylinders 　 6
Displacement L 6.494
Fuel tank capacity L 140
38 Transmission shift stage(front/rear-type) 　 2-2 automatic
39 Operating pressure Hydraulic system pressure kg/cm² 200

2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours

Application

Our 8 ton forklift is widely used in the port, wharf, industrial and mining enterprises, station, warehouse, and others.

After-sale service


Nowadays more than 60 agents around the world can supply LTMG professional after-sale service.
All the products of LTMG supplied with one year or 2000 workling hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product’s quality certificate.

Our company

2 Stage / 3 Stage Mast Forklift , Diesel Engine Forklift Truck FD100 2000 Working Hours

FAQ:

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
