2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
2 ton small forklift , diesel forklift truck with 3-stage mast
Specifications
Brand Name :
LTMG
Model Number :
FD20
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1unit
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
25days
Packaging Details :
nude packing, fit in container
Warranty :
1 year or 2000 working hours
fork length :
1070mm
lifting height :
4.5m
application :
can work in container
engine :
ISUZU engine
lifting capacity :
2000kg
attachment :
paper roll clamp, bale clamp
Ground clearence :
110mm
Description

2 ton small forklift , diesel forklift truck with 3-stage mast

2 ton forklift feature

1) Innovative Design;excellent operating performance
2) Wide-view Mast -- offer enhanced forward visibility, thus more efficiency and safty during operation;
3) Solid Overhead Guard -- specially designed for additional security;
4) Ergonomics Seat -- much more comfortable and fatigue-relieve able after long time operation;
5) Powerful Engine -- imported brand engine ensures high performance, safty and efficiency;
6) Super low & Non-slip step.

The specification of 2 ton diesel forklift

Features 1 Manufacturer LTMG
2 Model Power shift T/M FD20T
Manual shift T/M FD20C
3 Load capacity kg 2000
4 Load center mm 500
5 Power unit Diesel
6 Operator type Driver/seat
7 Tire type Front/rear Pneumatic
8 Wheel Front/rear 2/2
Dimension 9 Max. lifting height mm 3000
10 Free lift mm 160
11 Fork size L*W*T mm 1070*120*40
12 Tilt range Mast forward/backward deg 6/12
13 Overall length(without fork) mm 2460
14 Total width mm 1150
15 Mast height (fork lowering) mm 1995
16 Overall height fork raised With backrest mm 4030
17 Height to head guard mm 2120
18 Turning raduis(outside) mm 2170
19 Front face of fork to front axle mm 450
20 Min. right angle stacking aisle

without load

length&clearence

 mm 2615
Performance 21 Speed Max Travelling full/no load km/h 17/19
22 Liftin full/no load mm/s 550/580
23 Lowering full/no load mm/s 450/550
24 Max.drawbar pull Power shift T/M full/no load kg 1670/830
Manual shift T/M full/no load kg 1700/830
25 Gradeability at 1.6km/h Power shift T/M full/no load % 27/20
Manual shift T/M full/no load % 21/20
Weight 26 Truck weight kg 3330
27 Weight distribution Full load front/rear kg 4700/630
28 No load front/rear kg 1510/1820
Frame 29 Tires Number front/rear 2/2
30 Model front axle 7.00-12-12PR
31 rear axle 6.00-9-10PR
32 Wheelbase mm 1600
33 Tread Front/rear mm 970/970
34 Ground clearence At lowest point(mast) mm 110
Frame mm 115
35 Brake Service brake Hydraulic-foot pedal
Parking brake

Mechanical-hand

lever
Engine 36 Battery Voltage/capacity V/AH 12/80
37 Engine Model ISUZU C240
Rated power kw/rpm 34.3/2500
Rated torque N.m/rpm 138/1800
Number of cylinders 4
Placement L 2.369
Fuel tank capacity L 70
38 Transmission Speed forward/backward

Power shift T/M

Manual shift T/M

1-1 power

shift T/M

2-2 manual

shift T/M
39 Operating pressure Hydraulic system pressure kg/cm² 180

2 ton small forklift , diesel forklift truck with 3-stage mast

2 ton small forklift , diesel forklift truck with 3-stage mast

After sale service

Nowadays more than 60 agents around the world can supply LTMG professional after-sale service.
All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product’s quality certificate.

After-sale Service
LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with 1 year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.

Our company

2 ton small forklift , diesel forklift truck with 3-stage mast

FAQ:

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
