forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
Specifications
Brand Name :
LTMG
Model Number :
FD45
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
25 days after received your deposit
Packaging Details :
nude packing, fix in container
Type :
Powered Pallet Truck
overall dimension :
3100mm*1485mm*2270mm
weight :
7230kg
battery :
(12/80)*2 V/Ah
color :
yellow
engine :
ISUZU, Chinese engine, Mitsubishi engine
tires :
solid tire is optional
fork length :
1070mm
Description

forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift

Feature:

1.Scientific ergonomics design
2.Adjustable safety seat
3.Wide-view mast
4.High- mount exhaust system
5.Flexible steering system
6.Power-assisted brake
7.Optimal heat radiating& air duct system
8.Hydraulic transmission system
9.Easy available toolbox
10.Maintenance-free imported battery
11.Double air filter system (pre-filter and air-filter)

The specification of 4.5 ton forklift

Features1Manufacturer LTMG
2Model FD45T
3Load capacit kg4500
4Load center mm600
5Power unit Diesel
6Operator type Driver/seat
7Tire type Pnenumatic
8WheelFront/rear 2/2
Dimension9Max. lifting height mm3000
10Free lift mm140
11Fork sizeL*W*Tmm1220*150*50
12Tilt rangeMast forward/backwarddeg6/12
13Overall length(without fork) mm3100
14Total width mm1485
15Mast height (fork lowering) mm2300
16Overall height fork raisedWith backrestmm4190
17Height to head guard mm2270
18Turning raduis(outside) mm2780
19Front face of fork to front axle mm560
20Min. right angle stacking aislepallet size :1100×1100 add clearencemm4585
Performance21SpeedMax Travelling full/no loadkm/h18/19
22Lifting full/no loadmm/s410/430
23Lowering full/no loadmm/s380/340
24Max.drawbar pullfull/no loadkg4500/2000
25Gradeability at 1.6km/hfull load%25
Weight27Truck weight kg7230
28Weight distributionFull load front/rearkg10780/1290
29No load front/rearkg2780/4450
Frame30TiresNumberfront/rear2/2
31Modelfront axle300-15-18PR
32rear axle7.00-12-12PR
33Wheelbase mm2000
34TreadFront/rearmm1180/1190
Ground clearenceAt lowest point(mast)mm100
35Framemm240
BrakeService brake power brake
36Parking brake Mechanical-hand lever
Engine37BatteryVoltage/capacityV/AH2-12/80
38EngineModel MITSUBISHI S6S
Rated powerkw/rpm52/2300
Rated torqueN-m/rpm248/1700
Number of cylinders 6
DisplacementL4.996
39Fuel tank capacity L80
40Transmissionshift stage(front/rear-type) 2-1 power shift T/M
41Operating pressureHydraulic system pressurekg/cm²200


forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift


After-sale service
Nowadays more than 100 agents around the world can supply LTMG professional after-sale service.
All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product’s quality certificate.

Our company
forklift machine 4.5 ton forklift truck with Mitsubishi engine and side shift

FAQ:
1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.

Application

Our forklift truck is widely used in the port, wharf, industrial and mining enterprises, station, warehouse, and others.
