5000kg rated capacity diesel forklift truck with dual front tires
5000kg rated capacity diesel forklift truck with dual front tires
5000kg rated capacity diesel forklift truck with dual front tires
5000kg rated capacity diesel forklift truck with dual front tires
5000kg rated capacity diesel forklift truck with dual front tires
5000kg rated capacity diesel forklift truck with dual front tires
Specifications
Brand Name :
LTMG
Model Number :
FD50
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
25days
Packaging Details :
nude packing, fix in container
load center :
600 mm
Wheelbase :
2000mm
Tire :
dual front tires
Engine :
Mitsubishi engine, isuzu engine, Chinese engine
Warranty :
1 year or 2000 working hours
Overall dimension :
3455*1995*2500mm
fork size :
1220*150*60 mm
color :
customized
Description

5000kg rated capacity diesel forklift truck with dual front tires

5000kg diesel forklift Feature

1.New adjustable seat makes operator more comfortable.
2. Work lights and warning lights make it safer and more efficient even in poor lighting conditions.
3.New designed overhead guard protective device prevent the sudden accidents:The lifting system adopts buffering technology to reduce shock and vibration of the mast.
4. Bigger and non-slip step: Bigger and non-slip step make the operating convenient and safe
5. the full free 3-stage mast adopt German import channel With advanced welding technology , Increase the stability of ascension, durability and the width of front mast view, reduce the height of the instrument stand, expand the visibility of pallet fork tip and goods.

The Specification of 5000kg diesel forklift

Manufacturer
 　 　 LTMG
Model 　 Power shift T/M FD50T
Load capacity 　 kg 5000
Load center 　 mm 600
Power unit 　 　 Diesel
Operator type 　 　 Driver/seat
Tire type Front/rear 　 Pnenumatic
Wheel Front/rear 　 4/2
Max. lifting height 　 mm 3000
Free lift 　 mm 205
Fork size L*W*T mm 1220*150*60
Tilt range Mast forward/backward deg 6/12
Overall length(without fork) 　 mm 3455
Total width 　 mm 1995
Mast height (fork lowering) 　 mm 2500
Overall height fork raised With backrest mm 4420
Height to head guard 　 mm 2450
Turning raduis(outside) 　 mm 3250
Front face of fork to front axle 　 mm 615
Min. right angle stacking aisle without load length&clearence mm 5550
Speed Max Travelling full/no load km/h 26/30
Lifting full/no load mm/s 500/550
Lowering full/no load mm/s 450/500
Max.drawbar pull full/no load kg 5500/2250
Gradeability at 1.6km/h full load % 37
Max. Gradeability full/no load % 42/19
Truck weight 　 kg 8050
Weight distribution Full load front/rear kg 11710/1340
No load front/rear kg 4020/4030
Tires Number front/rear 4/2
Model front axle 8.25x15-14PR
rear axle 8.25x15-14PR
Wheelbase 　 mm 2250
Tread Front/rear mm 1470/1700
Ground clearence At lowest point(mast) mm 190
Frame mm 230
Brake Service brake 　 Brake booster Dynamic braking
Parking brake 　 Mechanical-hand lever
Battery Voltage/capacity V/AH 2x12V-80AH
Engine Model 　 ISUZU 6BG1 Chaochai 6102BG
Rated power PS(hp/rpm) 112/2000 110/2500
Rated torque kg-m max.(N.m) 42.5/1500 36/1650
Number of cylinders 　 6 6
Placement L 6.494 5.785
Fuel tank capacity L 140
Transmission Speed forward/backward Power shift T/M Manual shift T/M 2-2 power shift T/M
Operating pressure Hydraulic system pressure kg/cm² 200



5000kg rated capacity diesel forklift truck with dual front tires5000kg rated capacity diesel forklift truck with dual front tires

After-sale service
Nowadays more than 100 agents around the world can supply LTMG professional after-sale service.
All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product’s quality certificate.

Our company

5000kg rated capacity diesel forklift truck with dual front tires

FAQ:

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
