Factory Workshop Diesel Forklift Truck 15 Ton Capacity 1800mm Fork Length
Factory Workshop Diesel Forklift Truck 15 Ton Capacity 1800mm Fork Length
Factory Workshop Diesel Forklift Truck 15 Ton Capacity 1800mm Fork Length
Factory Workshop Diesel Forklift Truck 15 Ton Capacity 1800mm Fork Length
Specifications
Brand Name :
LTMG
Model Number :
FD150
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
USD59000-68000/Unit
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
200 units per month
Delivery Time :
35days
Packaging Details :
Nude packing, fixed in container
Type :
Powered Pallet Truck
Overall Dimensions: :
6950*2550*3240mm
Fork size: :
1800*180*90mm
Engine :
Yuchai engine or Cummins engine
warranty :
1 year or 2000 working hours
lifting height :
3m, 4m, 5m,etc
Description

Specifications of 15 ton diesel forklift:

FD150
FeaturesRated LoadQ(t)15
Load centerc(mm)600
Wheelbasey(mm)3800
WeightWeightkg24000
ChassisTyre Specs.:Front 12.00-24-18PR
Tyre Specs.:Rear 12.00-20-18PR
Tyres Qty,front/rear(X-drive wheels) 42
Wheel tread:Frontb10(mm)2060
Wheel tread:Rearb11(mm)2330
DimensionMast/carriage tilt angle(front/rear)Degree(°)612
Mast height(fork lowering)h1(mm)3625
Mast lifting heighth3(mm)3500
Max.lifting heighth4(mm)5375
Height to head guard(height to cab)h6(mm)3365
Overall height(with forks)l1(mm)7640
Fork front vertical surface to the rear end of the vehiclel2(mm)5840
Overall widthb1/b2(mm)2750
Fork dimensions/e(mm)1800X180X90
Fork carriage widthb3(mm)2380
Mast min ground clearance(with load)m1(mm)265
Wheelbase center min ground clearance(with load)m2(mm)325
Min.Turning radiusWa(mm)5800
Travel speed(with load/without load)km/h26/30
PerformanceMax.lifting speed(with load/without load)mm/s250/260
Max.Lowering speed(with load/without load)mm/s430/330
TractionN15000
Gradeablity(with load/without load)％20/22
Driving brake Hydraulic clamp disc
Engine brand/modelOptional oneYuchai engine
Engine YC6J175-T302
6.494L 129KW 2200rpm
Optional twoDongfeng Cummins
QSB6.7-C190
6.7L 142KW 2200rpm
Cylinder No.6
OthersTransmission gears(Front/rear) 21
Attachments working pressurebar160
Attachments using oil amountl/min60


Factory Workshop Diesel Forklift Truck 15 Ton Capacity 1800mm Fork Length
Factory Workshop Diesel Forklift Truck 15 Ton Capacity 1800mm Fork Length
Feature:
1. Steering axle: adopt full-hydraulic steering gear with transverse cylinder, which helps ensure flexible steering and high reliability
2. The gearbox and torque converter are of reliable quality and stable performance.
3. The transmission mode is hydraulic transmission (flexible transmission), being stable and convenient to operate.
4. Brake system is famous brand product, with reliable brake performance.

After-sale service
Nowadays we have been sell more than 100 countries.
All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product’s quality certificate.

FAQ:
1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
