1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color
1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color
1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color
1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color
1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color
1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color
Specifications
Brand Name :
LTMG
Model Number :
ERB15
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1/unit
Price :
USD 2043-2631 PER SET
Supply Ability :
300 Set/Sets per Month
Delivery Time :
30days
Packaging Details :
nude packing
Brand :
LTMG
Warranty :
1 year or 2000 working hours
Load capacity :
1500kg
Wheel base :
1325mm
Wheel type :
PU
Load center :
600mm
Battery capacity :
240Ah
Service weight with battery :
1390kg
Description

Curtis Controller 1.5t Battery Operated Electric Pallet Stacker with yellow color

Features of Curtis Controller 1.5t Battery Operated Electric Pallet Stacker with yellow color

1: Smart body, with attractive appearance. High-strength frame designed for tough pallet handling tasks.
2: Lower consumption, Lower service cost, while higher performance.
3: 24V/240AH maintenance free battery contributes to strong power and easier operation.
4: Compact structure and reasonable layouts provides steadiness and durability during operation.
5: Ergonomically designed and built Handle is increasing your comfort during operation. Dustproof and sealing structure prevent it from dust pollution damages and improve service life.
6: Intelligent and modular controlling system ensures the steadiness and safety for walking, lifting, lowering and braking.

The specifications of Curtis Controller 1.5t Battery Operated Electric Pallet Stacker with yellow color

Feature
Model 　 LTMG ERB15
Type 　 Narrow legs
Mast type 　 2-Stage STD
Operating type 　 Walk
Wheels
Wheel quantity driving wheel/Balance wheel/Bearing wheel 　 2001-2-4
Dimension
lift height mm 3000
Lowered fork height mm 85
Fork size(length/width/thickness) mm 1150/180/60
Overall length mm 1940
Overall width mm 850
Outside with between legs mm 600
Inside with between legs mm 230
Min.turning radius mm 1630
Min.aisle width for pallets 800×1200 mm 2180
Min.aisle width for pallets 1000×1200 mm 2210
Min.groud clearance mm 30
Performance
Travel speed,laden/unladen km/h 5/6
Lift speed,laden/unladen mm/s 95/130
Travel speed,laden/unladen mm/s 110/100
radeability,laden/unladen % 5/8
Electric configuration
Drive motor /Lift motor/Steering motor kw AC1.5/DC3.0/DC0.15
Battery voltage V 24
Brake 　 Electromagnetic/Regenerative
Controller 　 CURTIS
Weight
Battery weight kg 235

Curtis Controller 1.5t Battery Operated Electric Pallet Stacker with yellow color

1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color1.5t Battery Operated Electric Pallet Stacker Lift Truck Curtis Controller Yellow Color

After-sale service
Nowadays we have been sell more than 100 countries. All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
Detail clauses and policies please see to our website and product's quality certificate.
