Specifications
Brand Name :
LTMG
Model Number :
FG25
Certification :
CE ISO
Place of Origin :
Ningbo,China
MOQ :
1 units
Price :
USD 9600-12000 PER SET
Supply Ability :
300 units/month
Delivery Time :
30
Packaging Details :
fixed in container
Item :
short wheelbase forklift LPG
Engine :
NISSAN or other
Power type :
LPG Gasoline Forklift
Rated Capacity :
2500kg
Load Center :
500mm
lifting height :
3000mm
Gradeability :
20%
Fork size( L*W*T) :
1070*120*40
Fuel tank capacity :
55L
optional :
side shift ,fork positioner,mast type
Description

EPA approval engine 2.5 ton lpg forklift suitable for USA market

What are the features of the product:

1. Integrated Frame:The integrated frame further enhances durability & safety for long term operation.

2. Excellent front visual field:This not only ensure safety but also enhances working effiency.

3. Fashionable Dashboard:The fashionable dashboard is clear at a glance for the driver with exquisite screen & a combination of different meters.

4. For LTMG forklift, the engine hood is easy to open, this facilitates maintenance & repairation greatly. Application of man-machine theory can also be reflected from this detail.

Fast and stable performance
Being able to quickly raise and lower the mast, as well tilting forward and backward, the truck provides you the best operational conditions during loading/unloading operations. When the truck is full loaded, mast lowering speed is carefully controlled to ensure safety by the own control valve.

With the adopted common automotive cab layout, the operator requires no special training. The cab also provides both of mental and physical driving comfort, so as to ensure minimal load damage and accident over an arduous 8-hour shift. In addition, the forklift truck can be easily maintained by experienced mechanical engineers due to its simple design, thus ensuring reduced downtime.

The specification of EPA approval engine 2.5 ton lpg forklift

model   FG25
Power Type   LPG
Rated Capacity kg 2500
Load Center mm 500
lifting height mm 3000
Fork size( L*W*T) mm 1070*120*40
Mast Tilt Angle   6/12
Front Overhang mm 445
Length to face of fork mm 2360
Overall width mm 1110
Mast Lowered Height mm 2055
Mast Extended Height mm 4050
Overhead Guard Height mm 2080
Ground clearence mm 85
Turning raduis mm 2110
right angle stacking aisle mm 2316
Max.Travel km/h 17
Max.lifting mm/s 410
Wheelbase mm 1400
Front   21*7*15
Rear   16(1/4)*6*11(1/4)
Tread mm 902/900
Gradeability % 20
Truck weight kg 3900
Battery(Voltage/capacity) V/AH 12/80
Model   K25 EPA
Manufacturer   NISSAN
Rated output/r.p.m kw/rpm 42/2700
Rated torque N.m/rpm 185/1350
Number of cylinders   4
Bore*Stroke mm 89*100
Displacement cc 2488
Fuel tank capacity L 55
Optional engine : K25/K25EPA/PSI 3.0/PSI 3.0EPA

EPA Approval Engine Gasoline Forklift Truck , 2.5 Ton Lpg Forklift BLUE

EPA Approval Engine Gasoline Forklift Truck , 2.5 Ton Lpg Forklift BLUE

Export country and information :

LTMG Machinery is a professional forklift manufacturer, forklift and related products has been exported to more than 60 countries.The quality of our forklift is recognized by our customers.

After-sale service

Nowadays we have been sell more than 60 countries.

All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Detail clauses and policies please see to our website and product’s quality certificate.
