LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
Specifications
Brand Name :
LTMG
Model Number :
FDS100
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
USD 59705 PER SET
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Delivery Time :
30days
Packaging Details :
nude packing, in container
Overall Dimensions: :
6250*2620*3240mm
warranty :
1 year
engine :
Chinese engine or ISUZU engine
lifting height :
3.6m
mast :
two stage mast
engine power :
77.2KW
Description

10 ton side loader forklift truck with CE SGS ISOcertificate

10 ton side loader forklift feature

1. Equipped with Chinese powerful and reliable engines with excellent environmental performance; Original imported Isuzu, Mitsubishi and Cummins engines are optional.
2. Install heavy-duty driving axle to ensure safety work at bad working conditions.
3. Adopt advanced load sense technology which offers flow for steering system to save energy ,protect environment ,and lower the system heat.

The specification of 10 ton side loader forklift

ITEM FDS100
Transmission Hydraulic
Max. lifting capacity/Load center (kg/mm) 10000/600
Max. lifting height (laded) (mm) 3600
Fork free lift (mm) 400
Max. lifting speed (laded) (m/s) ≥0.25
Traveling speed (km/h) Forward I 8.3
Forward II 31.8
Reverse 11.25
Fork tilt anger (front/rear) 5/3
Min. turning radius (mm) 5800
Gradeability (laded) (%) 20
Mini. ground clearance (laded) (mm) 220
Dimension (mm) Length 6200
Width (without rearview) 2600
Height Fork lowered 3450
Fork rised 5230
Wheel base (mm) 3700
Wheel track (mm) 2200/2110
Platform height (mm) 1340
Platform width (mm) 1760
Fork length (mm) 1650
Max. fork spacing (mm) 1310
Tire model (front/rear) 2/4 12.00-20-18PR
Weight unladed (kg) 15000
Engine Model LR6105G6X
Rated power (Kw/rpm) 77.2/2200
Max. torque/speed (N.m/rpm) 372/1400


LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
LTMG 10 Ton Side loader Forklift Trucks hydraulic lift truck with SGS CE Certificate
After-sale Service
Nowadays more than 100 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
