dual fuel suspension seat forklift Truck 3 .5 Ton with nice color
dual fuel suspension seat forklift Truck 3 .5 Ton with nice color
dual fuel suspension seat forklift Truck 3 .5 Ton with nice color
dual fuel suspension seat forklift Truck 3 .5 Ton with nice color
Specifications
Brand Name :
LTMG
Model Number :
FG30
Certification :
CE,ISO
Place of Origin :
Ningbo,China
MOQ :
1
Price :
USD 11500-19000/ Unit
Supply Ability :
300 units month
Delivery Time :
30
Packaging Details :
fixed in container
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Ground clearence :
120mm
optional :
side shift, fork extension,cabin ,air-conditioner
Wheelbase :
1700mm
Load capacity :
3500kg
Load center :
500mm
engine :
Nissank25
tire :
Pneumatic
transmission :
hydraulic
Description

dual fuel suspension seat forklift Truck 3 .5 Ton with nice color


Feature:
1, LPG forklift truck, Gas power forklift
2, Material Handling, loading & unloading cargo, moving cargo in pallets
3, 3500kg rated capacity, 3000mm lifting height, 500mm load center
4. Nissank25 engine available
5. China transmission available

LTMG offers innovative design that integrates high end features & reliability without the high end price tag. They are durable enough to stand up to even the most challenging material handling applications. forklift offer accessible maintenance, straightforward operation, enhanced operator ergonomics, and dedicated attention to detail with operator safety in mind. All forklifts have CE Certification, are produced in an ISO9001 accredited facility,


dual fuel suspension seat forklift Truck 3 .5 Ton with nice color
Specification of 3.5 ton forklift truck

Features Manufacturer 　 　 LTMG
Model 　 Power shift T/M FG35
Manual shift T/M FG35
Load capacity 　 kg 3500
Load center 　 mm 500
Power unit 　 　 Gasoline
Operator type 　 　 Driver/seat
Tire type Front/rear 　 Pneumatic
Wheel Front/rear 　 2/2
Dimension Max. lifting height 　 mm 3000
Free lift 　 mm 150
Fork size L*W*T mm 1070*125*50
Tilt range Mast forward/backward deg 6/12
Overall length(without fork) 　 mm 2720
Total width 　 mm 1285
Mast height (fork lowering) 　 mm 2075
Overall height fork raised With backrest mm 4250
Height to head guard 　 mm 2140
Turning radius(outside) 　 mm 2460
Front face of fork to front axle 　 mm 485
Min. right angle stacking aisle without load length&clearance mm 2940
Performance Speed Max Travelling full/no load km/h 18/19.5
Lifting full/no load mm/s 450/500
Lowering full/no load mm/s 450/420
Max.drawbar pull Power shift T/M full/no load kg 1800/1000
Manual shift T/M full/no load kg 1900/1000
Gradeability at 1.6km/h Power shift T/M full/no load % 17/20
Manual shift T/M full/no load % 17/20
Weight Truck weight 　 kg 4610
Weight distribution Full load front/rear kg 7260/850
No load front/rear kg 1840/2770
Frame Tires Number front/rear 2/2
Model front axle 28x9-15-12PR
rear axle 6.50-10-10PR
Wheelbase 　 mm 1700
Tread Front/rear mm 1060/970
Ground clearance At lowest point(mast) mm 120
Frame mm 135
Brake Service brake 　 Hydraulic-foot pedal
Parking brake 　 Mechanical-hand lever
Engine Battery Voltage/capacity V/AH 12/60
Engine Model 　 Nissan K25
Rated power PS(kw/rpm) 51/2300(37.4/2300)
Rated torque kg-m max.(N.m) 18/1600(177/1600)
Number of cylinders 　 4
Displacement L 2.488
Fuel tank capacity L 70
Transmission Speed forward/backward Power shift T/M Manual shift T/M 1-1 power shift T/M 2-2 power shift T/M
Operating pressure Hydraulic system pressure kg/cm² 180

After-sale Service:

LTMG always treat after-sale service as important as sale.
All the product of LTMG supplied with one year or 2000 working hours (whichever occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
