2 Stage Mast Straddle Pallet Stacker , Pedestrian Counterbalanced Forklift
2 Stage Mast Straddle Pallet Stacker , Pedestrian Counterbalanced Forklift
2 Stage Mast Straddle Pallet Stacker , Pedestrian Counterbalanced Forklift
2 Stage Mast Straddle Pallet Stacker , Pedestrian Counterbalanced Forklift
Specifications
Brand Name :
LTMG
Model Number :
ERB20T
Certification :
CE ISO
Place of Origin :
Ningbo,China
MOQ :
1 units
Price :
USD 7000-10000 / unit
Supply Ability :
1000units
Delivery Time :
30 days
Packaging Details :
nude packing, fixed in container
Payment Terms :
Western Union, MoneyGram
Power type :
AC & DC motor
warranty :
1 year/2000 working hours
Controller :
CURTIS
Service weight with battery :
1280kg
Battery capacity :
280Ah
Load center :
600mm
Mast type :
2-stage mast
Description

LTMG 2 ton 2.5 ton full electric pallet straddle stacker with Curtis controller

1. Germany system technology of warehousing equipment and leading international level.

2. The product with the principle of human engineering, fully humanized design.
3. The equipment using the German imports of seal, bearing and electrical components,further to ensure the reliability of the vehicle.
4. Using USA or Italy electronic assembly control, the German import control handle and Italy Metalrota driving wheel,and fully guarantee the stability of vehicle.

Main Features:

- Capacity:1500kg, Curtis controller, brand spare parts make
use stable quallity and long-life using, H steel strong mast,
double cylinders make lifitng very smoothly
- Lift height is 4.5m, the max. lift height can be 7.0m
- Heavy-duty designed, for long-term work
- Import German Mahle pump/motor, German brake
- 24/240Ah lead-acid battery, long use time and long life
- Strong structure body and strengthen fork, no bending
- Emergecy stop/hour meter/Battery level indicator AC

2 Stage Mast Straddle Pallet Stacker , Pedestrian Counterbalanced Forklift

Model 　 ERB20T
Type 　 Narrow legs
Mast type 　 2-Stage STD
Load capacity kg 2000
Load center mm 600
Wheel base mm 1325
Operating type 　 Walkle/Stand on
Wheels
Wheel type 　 PU
Demension
Standard lift height mm 3000
Lowered fork height mm 86
Fork size(length/width/thickness) mm 1150(1200)/180/60
Overall length mm 1970/2390
Overall width mm 1050
Outside with between legs mm 570/600/650/685
Inside with between legs mm 180/230/280/315
Min.turning radius mm 1630/1990
Min.aisle width for pallets 800×1200 mm 2180/2580
Min.aisle width for pallets 1000×1200 mm 2210/2600
Min.groud clearance mm 30
Performance
Travel speed,laden/unladen km/h 5/5.5
Lift speed,laden/unladen mm/s 80/120
Travel speed,laden/unladen mm/s 80/90
Gradeability,laden/unladen % 5/8
Electric configuration
Drive motor /Lift motor/Steering motor kw AC1.5/DC3.0/DC0.15
Battery voltage V 24
Battery capacity Ah 280
Brake 　 Electromagnetic/Regenerative
Controller 　 CURTIS
Weight
Battery weight kg 235
Service weight with battery kg

1280

After Sales Service:

LTMG always treat after-sale service as important as sale.
All the product of LTMG supplied with one year or 2000 working hours (whichever occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
