1000-2000kg Rated Capacity Explosion Proof Trolley 48/80v Battery Voltage
1000-2000kg Rated Capacity Explosion Proof Trolley 48/80v Battery Voltage
Specifications
Brand Name :
TOPSKY
Model Number :
LT-1.5T/3.0T
Place of Origin :
China
MOQ :
1 set
Price :
USD2800-USD3000
Payment Terms :
T/T
Delivery Time :
15 working days
Packaging Details :
Export package
Name :
Coal mine electric trolley LT-1.5T/3.0T
Rated load :
1500kg
Load center distance :
600mm
Self -weight (including battery) :
230kg
Standard for maximum uplink height :
115mm
Vehicle length :
1638mm
Description


1.Product overview
Explosion-proof trolley refers to a class of trolley with explosion-proof performance. The main battery explosion-proof forklift and battery explosion-proof trolley. The factors causing the explosion such as spark, static electricity and temperature are dealt with comprehensively. The motor and electrical appliances are designed for flameproof type, and the power supply device is designed for explosion-proof special type.
2.Scope of application
It is suitable for dangerous places with explosive gas mixtures in petroleum, chemical, textile, pharmaceutical, food, national defense and other industrial sectors for loading and unloading, handling, stacking and other operations.
3.Product Features

3.1 Installation of explosion -proof weighing system
Our type can add explosion -proof weighing systems for you. It uses four high -precision explosion -proof sensors, one security explosion -proof wiring box, a 315 explosion -proof weighing meter, and can be added with Bluetooth and WIFI weighing signal transmission.
3.2 Customized fork ruler
When we encounter some special industries and purposes, the conventional and selected fork ruler size cannot meet our requirements, and we can provide you with non -standard size customization.
3.3 Fork ruler cover stainless steel
The raw materials of some industries are corrosive. The conventional carbon steel fork arm loss is large and the durability is low. We can cover a layer of stainless steel on the surface where the materials may be exposed to increase the durability of the product.

4.Main Specifications
ModelUnit1.5T2T3T
Dynamic electricelectricelectric
Type WalkingWalkingWalking
Rated loadQ(kg)150020003000
Load center distancec(mm)600600600
Bearer lengthx(mm)883/946874/962877
Wheelbasey(mm)1202/12611248/13361205
Self -weight (including battery))Kg230290460
Tire type, drive wheel/bearing wheel (rotor wheel) PolyurethanePolyurethanePolyurethane
Standard for maximum uplink height(mm)115115115
Operation location Handle rod minimum/maximum height(mm)750/1170750/11701200
The height after the fork drops(mm)808085
Vehicle length(mm)163816851638
The length of the vertical surface of the fork(mm)488535590
Overall width(mm)560(685)560 (685)694
Fork size(mm)50/150/115050/150/115054/150/1220
Fork outside width(mm)560(685)560(685)560 (685)
The width of the right -angle stacking channel (the tray is 1000 length × 1200 width)(mm)230423041739
The width of the right -angle stacking channel (the tray is 800 width × 1200 long)(mm)237123711939
Walking speed, full load/empty loadkm/h4.5/54.5/54.5/5
Raise speed, full load/empty loadm/s0.027/0.0380.018/0.0370.024/0.038
Down speed, full load/empty loadm/s0.059/0.0390.032/0.0380.059/0.039
Maximum climbing angle%450624515445087
Driving brake type ElectromagneticElectromagneticElectromagnetic
Drive motor rated power s260 minutesKW0.750.750.75
Rate -lift motor rated power S315%KW0.840.840.84
Battery voltage/nominal tolerance violenceV/Ah2x12/6548V/302x12/100
Drive control type DCDCDC
Steering type mechanicalmechanicalmechanical
Drive unit type DCDCDC
Noise level SdB(A)747470
