High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig
High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig
Specifications
Place of Origin :
China
Brand Name :
GOLD
Model Number :
MGJ-50A
Certification :
CE
Price :
20000
Packaging Details :
Plastic sheeting or wooden case
Delivery Time :
10 week working days
Payment Terms :
T/T L/C Western Union
Supply Ability :
100 set /month
MOQ :
1set
Description

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

MGJ-50L crawler drill rig for anchoring and jet-grouting is a type of integration of crawler, mud pump and control panel based on original MGJ-50 drill rig for anchoring and jet-grouting.
The drilling rig is mainly used in soil and rock anchoring, consolidation of road base, dam base and retaining wall, and blasting hole drilling and jet-grouting.

The picture of Blasting Hole Drilling Rig

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

What's the feature of our Blasting Hole Drilling Rig?

1.The drill rig is with mechanical transmission and hydraulic feed, drill hole diameter is mainly 110— 130mm(can reach 180mm), drilling capacity 60m, can drill at any angle between horizontal

andvertical

2.Long feeding stroke reaching 2300 mm with 2 m drill rod

3.Using with rotation drilling and percussion –rotation drilling, drill efficiently

4.Support cylinder, it is easy to adjust the angle of the mast

5.With crawler, it is easy and fast to find out the drill hole position

What is the technical parameter of our Blasting Hole Drilling Rig?

Depth: 60m

Diameter: 110-130mm, can reach 180 mm

Drilling angle: any angle between vertical and horizontal

Crawler:Max. tow force: 27.5KN, Speed：1.17 km/h

Dimension：Drilling vertical hole：3130×1920×4090 mm

Drilling horizontal hole：3550×1920×1820 mm

Whole weight：2850kg

What's the accessories of Blasting Hole Drilling Rig

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling RigActivities Display

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling RigWhy choose us?

1.We have more than6 yearsof developed sales chanels inmany countries.

2.Our company arehighly acclaimed and favorablyaccepted by numerous customers and possessed of the right to import and export.

3.We prominent emphasize the humanconcern,respect,rustin company management,as we as stimulate staff'ssense of responsibilityandthe sense of mission.

4.Inspected by the Inspection Institution ofBureau Veritas Certification.

5.100% QCinspection Before Shippment.

6.CE/FClisted,competitve price.effective delivery.

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling RigTrade Terms

1.Payment:T/T,Western Union,L/C

2. Delivery Time:within 10 week working days

3.Warranty:1 Year

4.Packing information:wooden cases with standard exporting package

Our packing way for your reference

High Efficient Drilling rig with Crawler 60m Blasting Hole Drilling Rig

FAQ:

Q1.Are you trading company or manufacturer?

We are absolutely professional manufacturer, and our factory mainly producewater well drilling rig,core drilling rig,piling rig, etc.

We provide comprehensive solution to many fields like geological survey, mining industry, electric power etc.

Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.

.

Q2.Do you have after service?

Yes, we havespecial service teamwhich will offer you professional guidance. If you need, we can send our engineer to your worksite and provid the training for your staff.

Q3.Is there cheap shipping cost to import to our country?

A1:Sea ship wayis best for drilling rig transportation

Q4:Can we get support if we have our own market position?

A2: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.
