Plastic Refreshing Keg Draft Beer Filling Machine Including Stainless Steel
Plastic Refreshing Keg Draft Beer Filling Machine Including Stainless Steel
Plastic Refreshing Keg Draft Beer Filling Machine Including Stainless Steel
Plastic Refreshing Keg Draft Beer Filling Machine Including Stainless Steel
Specifications
Brand Name :
GD
Model Number :
GD
Certification :
CE, UL,ISO
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
TT
Supply Ability :
20 sets per month
Delivery Time :
25 working days
Packaging Details :
iron frame /plate
Type :
Filling Machine
Condition :
New
Application :
Beverage, Chemical, Commodity,
Packaging Type :
Barrel, Bottles, Cans, jars, tins
Automatic Grade :
Automatic
Driven Type :
Pneumatic+electric
Voltage: :
AC220V or AC380V
Material :
SS 304 and alloy
warranty :
12 months
Description

CGET, internationally-known brand for brewery equipment and package line

Plastic Refreshing Keg Draft Beer Filling Machine Including Stainless Steel


The machine characteristics:

This machine is designed for the washing and sterilizing work of all kinds of beer refreshing containers (including stainless steel refreshing keg and draught beer keg). And this machine can do the works washing, sterilizing and CO2 pressure preparing automatically.

The control unit of this machine uses the LS Programmable controller and WEINVIEW human-computer interface . All of the controls parameters ( time value ) can be adjusted when it is running . This machine is easy to operate . Simple and reliable!
Technical parameter

Air pressure: 0.6----0.8Mpa

Wine source pressure: 0.2----0.3Mpa

CO2 pressure: 0.2----0.3Mpa

Cylinder pressure: 0.4----0.5Mpa

Electric source pressure: 208V 60HZ


Primary structure

Main specification and size:

Worktable size: 960mm x 480mm

Worktable height: 160mm

Machine outside measurement: 960mm x600mm x1530mm

Piston maximum stoke: 300mm

Net weight: 106kg

Ability: 60 ～100kegs/hour

Filling style: upright filling

Kegs’ size (mm): Diameter: betweenф250～500

Height: between 410～650mm

Primary structure:

This machine is made up of stander, electric control system, solenoid valve, pneumatic element, and wine back system etc. parts. See attachment.

Plastic Refreshing Keg Draft Beer Filling Machine Including Stainless Steel
