220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems
Specifications
Brand Name :
CGET
Model Number :
CG-200
Certification :
CE ISO9001
Place of Origin :
Shandong, China (Mainland)
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300set per year
Delivery Time :
30 working days
Packaging Details :
Iron crate, wooden box, suitable for long distance sea transport packaging or Wooden case
Processing :
Fermenting Equipment,
Condition :
New
Processing Types :
Beer
Voltage :
220V/380V
Product :
Micro Beer Brewery Brewhous
Material :
Stainless Steel 304/ 316
Application :
Brewpub or micro brewery
warranty :
12 month
Description
220V / 380V Microbrewery Equipment Beer Making Plant Turnkey Brewpub Systems

Micro Beer Brewery 200 300L 500L 1000L Brewhouse Beer Brewing Mash Tun System

Mash Tun Advantages
• New technology and Engineer from Jinan Shandong.
• High standard materials, stainless steel, nice appearance.
• The parts use famous brand.
• The Seamless welding, good sealing performance
• The beer is very delicious and nutritious for body.

Mash Tun Speification

• 20L-10000L capacity
• Factory manufacture with low price
• Hot sale model

1/5-100 HL Brewing Equipment Lists
System
Components
Specification
Material
Brand
QTY
Brewhouse
Malt milling
Double roller
Stainless steel
1
Mash tun/lauter tun
500/850L
SS304
CGET
1
Wort kettle/
whirlpool
500/850L
SS304
CGET
1
Platform
SS304
CGET
1
Brewhouse &
fermentation
Control system
PLC
China
1
Plate heat exchanger
6㎡
SS316
China
1
Wort aeration
plant
SS304
CGET
1
Brewhouse
piping system
SS304
CGET
1
Hot water tank
1000L
SS304
CGET
1
Ice water tank
1000L
SS304
CGET
1
Hot water pump/Ice water pump
3T/h
SS304
CGET
2
Cellar
CCT
1000/1300L
SS304
CGET
8
Yeast Storage
Tank
150/200L
SS304
CGET
3
Yeast pitching
pump
SS304
CGET
1
Fermenter
control cabinet
PLC
CGET
1
CIP system
150L
SS304
CGET
2
Fermenting
piping system
SS304
CGET
1
Aseptic
membrane
filtration system
0.45/0.01μ
2
Beer pump/CIP Return
5T/h
SS304
CGET
2
Utility system
Electric heating generator
150kg
China
1
Cooling system
6HP
China
1
Alcohol tank
1000L
SS304
CGET
1
Alcohol pump
5T/h
SS304
CGET
1
Attachment configuration
SS304
CGET

Advantages:
1. Complete, new, and high quality configuration.
2. Auxiliary systems selection of leading and imported brand.
3. The auxiliary systems are long life, high-performance, high-quality, low-loss.
4. Certified stainless steel(304,316) material for all tanks.
5. Electrical accessories reach CE, PED,LVD export standards.
6. Supporting auxiliary system voltage and frequency match your standard exactly.
7. New production technics.
8. Stable quality, high performance, strict quality control.
9. All the equipment are adopted 100%TIG welded joints, mirror Polishing.

Packaging & Delivery
Packaging Details
Micro Beer Brewery 300L 500L 1000L Brewhouse Beer Brewing Mash Tun System package:
By independent containers or by bulk carriers PVC film, or wooden case, or steel frame.
1. All tanks will be packaged with soft protection material and mounted on strong carbon steel frame
2. All accessories and spare parts will be packaged with separated box.
3. After loaded into containers, all equipment will be tightly fixed to the containers.
Port
qingdao

1. Q: It's the first year(1st year) for you to produce brewing equipments?
A: No. We have worked in this business for more than Twenty-one years years,
2. Q:How many years is your warranty ?
A: The the warranty of main engine is 3 years, and auxiliary is 1 year.
3. Q: Can you do OEM or ODM?
A: Yes, we can do both.
4. Q: How to control temperature ?
A: PLC or digital display meter can control the temperature via connecting with the PT100 sensor.
5. Q:Ask:how to install the machine ?
Answer:You can install the machine under the instruction of video, email or photo .if for the large project , we can arrange the worker help you to install it in your country .
6. Q: Is customized available ?
A: Yes.
