Small Commercial Brewing Equipment Fitted In One 40Hq Container Direct Heating

microbrewery turnkey brewery complete brewery whole plant, fitted in one 40HQ container

Fermentation tank, conical tank, pressurized

bright beer tank for maturation, jacketed, glycol cooling, stainless steel

CGET, with 20 year manufacturing history.

Suitable for limited budget, especially an economic equipment of basic technology but of constructive quality and professional design, that can be assembled easily by means of the labeling of its components and once assembled and connected it is plug and play, to be operated with ease in the brewing and CIP cleaning processes.

Four stainless steel legs, with feet for leveling and height adjustment, base plate with two holes for fixing to the floor; with reinforcements between the legs. - With lifting lug on top of tank

A.- Brewery equipment A1.- Malt Mill 300-500 kg / h A2.- Hot Liquor Tank of 1,500 liters A3.- Brewhouse of 3.5bbl Combitank / Heating by fire direct in enclosed chamber Type: Two Tank / Three Vessel European style elaboration process Vessel: Mash Tun / Kettle + Combitank: Lauter Tun and Whirpool below A3.1.- Mash Tun / Kettle - Minimum workload of 3.5bbl+15% head space. - Heating by direct fire in enclosed chamber, (not include burner). Include a description of the main features, insulation, etc. - Type of agitation: VFD variable speed gearmotor with smooth agitation for Mash temperature homogenization. - Hidrator with 4 "Triclamp port and connection with 4" butterfly valve - Total drainage port - Port of partial drainage in bottom, equal to a clean exit port of Whirpool - Manhole with a minimum diameter of 400 mm - Glass liquid level of sanitary type in liters / with connection to CIP circuit - 360 ° CIP 2 spraying ball - 6" Venting port and steam condensation pipe - Thermowell with temperature probe PT-100 A3.2.- Combitank: Lauter Tun up / Buffer Tank Whirpool below - Heating: NO - Insulation: PU 50 mm / Rock wool; TH = 50mm Specifications of the lauter tun: - Minimum working volume of the Lauter Tun 900 liters +% head space - With lifting lug on top of tank. - Manhole in top of 400 mm minimum / without shadows to CIP. - Rectangular side manhole of 530x430 mm to extract the spent grain and the false bottom sieve. With removable guide plate under the exit door.
