Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
Specifications
Brand Name :
CGET
Model Number :
500L
Certification :
CE Ul ISO2001
Place of Origin :
china shandong
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300 Set Per year
Delivery Time :
40 Work Days
Packaging Details :
Iron crate, wooden box, suitable for long distance sea transport packaging or Wooden case
Processing :
Fermenting Equipment
Condition :
New
Processing Types :
Beer
Voltage :
220V , 380V
Keywords :
Brewpub Beer Equipment
Heating way :
electric
Description

Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel

Fermenters description

The conical fermentation tanks have a dished top with cylindrical body. The 60 degree conical bottom is ideal for fermenting and improving the quality of beer as well as breeding yeast. All the tanks are food grade stainless steel 304 with a 3mm thickness for 100l-5000l, but larger tank is 4mm thickness. The cooling system is a dimple jacket with insulated polyuranthane filling.

It is 100% stainless steel. All tanks comes with 25% head space on top of working volume. All cone come with racking arm. It allows you to start your siphon with the racking arm horizontal, and rotate it slowly downward until you just start picking up yeast sediment.

Product Description

• Mash Lauter Tun with grist hydrator

• Kettle Whirlpool Tank with heating jacketed

• Grant Tank

• Stainless steel Platform

• Plate Heat Exchanger

• Sanitary Wort Pump x2;

• Wort Oxygenator;

• Semi-Auto Control Panel;

• Interior surface to finish pickled and passivated

• Exterior surface to brushed, #4 finish

Or

• Interior surface to polished to RA≤0.22μm

• Exterior surface adapts satin polish.

Method of Heating Ways:

• Steam: Dimple plate jacket with inlet/outlet fittings for Steam heat transfer;

• Electric: Use electric heaters in jacket to heat the medium in the jacket

• Gas fired: Use gas burner at bottom to heat tank directly;

No name components specification
1 Grain Milling Unit Rolling Miller Double roller
Speed differential
2 Brewhouse unit Mash/Lauter tun Grain rake with VFD
Laser cutting V-wire False Bottom
Easy clean and detachable sparging spray ring
Multihole wort collect ring(optional)
Anti-rinser(optional)
Kettle/Whirlpool Tun Steam Jacket on bottom and side/direct gas fired heating/electric heating
Steam vent with condensate ring for kettle stack
Hot water tank Steam Jacket heating/direct gas fired heating/electric heating
Heat exchanger SUS304 plate
3 Fermentation unit Fermenter Glycol cooling jacket on cone and bottom
Side or top manway
CIP arm and CO2 blow off arm
Germany import Kieselmann Mechanical relief valve
Shockproof pressure gauge
Rotating racking arm
Dry hopping port
Carbonation stone
Sight level
4 Bright beer tank Bright beer tank Glycol cooling jacket on cone and bottom
Side or top manway
CIP arm and CO2 blow off arm
Germany import Kieselmann Mechanical relief valve
Shockproof pressure gauge
Rotating racking arm
Dry hopping port
Carbonation stone
Sight level
5 Glycol Chilling Unit Glycol Water Tank Insulated conical top and sloped bottom
Cold Water Tank Dimple plate on side wall
Chiller
6 Control unit Brewing and fermetation process Controlling Manual button control panel or PLC control with touch screen for special
7 CIP unit Caustic Tank electric heating element inside
Sterilization Tank
Transfer&Control
8 Others

Shockproof Electric Commercial Microbrewery Equipment Semi Auto Control Panel
