Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage
Specifications
Brand Name :
CGET
Model Number :
CG-
Certification :
CE UL ISO
Place of Origin :
Shandong, China (Mainland)
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300Set Per Years
Delivery Time :
40Work Days
Packaging Details :
iron frame
Processing :
Fermenting Equipment
Condition :
New
Processing Types :
Beer
Dimension(L*W*H :
Capacity Request
Weight :
depnds on capacity
Voltage :
3phase/380(220,400,415,440)v/50 (60)Hz
Dimension(L*W*H) :
customized
After-sales Service Provided :
Engineers available to service machinery overseas
Name :
Beer factory fermenter
Description

Large Scale Industrial Beer Brewing Equipment 3000l 5000l Adjustable Voltage

Mashing system:

Structure

3-Vessel:Plan A: Mash tun-Lauter tank-Kettle/whirlpool

Plan B: Mash/lauter tank-Kettle-Whirlpool

4-Vessel:Mash tun-Lauter tank-Kettle-Whirlpool

Extra hot liquor tank

Extra cooker at customer's chois

Malt grinder SUS304/COPPER Double roller miller
Interior SUS304 Thickness:3.0mm
Exterior SUS304/COPPER Thickness:2.0mm
Agitator SUS304 Optional
Mayway SUS304 Top glass manway
Spent grain door SUS304 Side spent grain manway
Wort pump SUS304 High efficiency sanitary pump
Heating Steam Stainless steel dimple jacket
Temperature control PT100/
Sparging ring SUS304 Optional
False bottom SUS304 Milled sieve plate
Cleaning SU304 360° spary cleaning ball
Cooling Heat exchanger double stage/single stage
Sight glass Inline type Optional
Hot liquor tank SUS304/COPPER Capacity assort
Wort collection pipe SUS 304
Wort grant SUS304 Capacity assort
Hopback tank SUS304/ Capacity assort
Steam condensing SUS304 Optional
Screw conveyor SUS304 Optional

Fermentation system:

Fermenter SUS304/COPPER 3000L-20000L
Interior SUS304 Thickness 3.0mm
Exterior SUS304 Thickness 2.0mm
Bottom cone 60-75 degree Yeast outlet
Cooling method Glycol cooling Dimple jacket
Temperature control PT100
Pressure display Pressure gauge
Pressure relief SUS304 Pressure relief valve
Cleaning SUS304 360° spary ball
Insulation layer Polyurethane 100mm
Manway SUS304 Top/side manway
Sampling valve SUS304 No dead coner
Dry hops adding port SUS304 Optional, clamp type
Yeast adding tank SUS304 Capacity assort
Bright beer tank SUS304 3000L-20000L

Necessary auxiliary system:

Cooling SUS304

Glycol water tank

Cold water tank

Chiller Branded 10~25HP
Glycol water pump Branded High efficiency sanitary pump
Control PID/PLC Branded electrical components
Cleaning SUS304 CIP system

Beer filling/packaging System:

- Automatic beer bottling line

- Automatic beer canning line

- Automatic beer kegging line

Company Information

Kelang company ,founded in 1997,is a service-outsourcing and new high-tech enterprise in fermentation engineering industry,Provide the customers with systemic solution of non-standard technical renewal on the fermentation field,is committed to the first person on the fermentation service outsourcing field.

Company provides fermentation project technology service to enterprises in the area of Alcohol, condiment, biopharmacy and any other bio-fermenting lines.Service is including technology proposal design,a complete set of equipment,application project installation,training technicians,financing service etc five system links.

Our products have been exported to many countries in the world,and our company has established long-term and friendly cooperative relations with Russia, the United States, Canada, Britain, Australia, New Zealand, Kenya, Moldova, Israel, Singapore, Philippines, India, Holland and many other countries and regions,awarding high praise from our customers.
