Overhead Crane Accessories Square Solid Steel Bar / Hot Rolled Steel Flat Bar
Overhead Crane Accessories Square Solid Steel Bar / Hot Rolled Steel Flat Bar
Specifications
Brand Name :
NANTE
Model Number :
70*40, 50*30, 60*40
Certification :
CE
Place of Origin :
Zhejiang
MOQ :
1ton
Price :
usd650-690/ton
Payment Terms :
L/C, T/T
Supply Ability :
1000000 ton/year
Delivery Time :
7 working days
Packaging Details :
in nude
Material :
Q345B
Color :
Can be painted
Treatment :
Hot rolled
Surface :
Smooth
Length :
5.8ms/pc
Description

Specifications:

Steel Bar/Steel Rod
Standard ASME, ASTM, AISI,EN ,BS,GB,DIN, JIS,etc
Size/Thickness φ40mm-φ480mm
Length 3000mm-6000mm
Material

1Cr17Mn6Ni5N(201),1Cr18Mn8Ni5N(202), 0Cr18Ni9(304),00Cr19Ni10(304L),0Cr17Ni12Mo2(316),

00Cr17Ni14Mo2(316L),1Cr18Ni19Ti(321),

0Cr25Ni20(310S),0Cr23Ni13(309S),1Cr19Ni11Nb(347H),

1Cr17Ni7(301),1Cr18Ni9(302),Y1Cr18Ni9(303),etc
Packing Standard export sea-worthy package, or as customers' requirements
Delivery Time Within 7-15 working days
Quality High quality
Brand Name TISCO, JISCO,BISCO,KSK,BG
Productivity 500MT/Month
MOQ 1MT
Note The quality of the products is something we never neglect. Good quality can ensure continued sales. Our company has carried out effective quality assurance and long-term plan to improve products quality.


Size:

Size
(mm)		 Cross section area
(cm2)		 Theoretical
weight
(kg/m)		 Size
(mm)		 Cross section
area
(cm2)		 Theoretical
weight
(kg/m)
5 0.25 0.196 30 9.00 7.06
6 0.36 0.283 32 10.24 8.04
7 0.49 0.385 34 11.56 9.07
8 0.64 0.502 36 12.96 10.17
9 0.81 0.636 38 14.44 11.24
10 1.00 0.785 40 16.00 12.56
11 1.21 0.95 42 17.64 13.85
12 1.44 1.13 45 20.25 15.90
13 1.69 1.33 48 23.04 18.09
14 1.96 1.54 50 25.00 19.63
15 2.25 1.77 53 28.09 22.05
16 2.56 2.01 56 31.36 24.61
17 2.89 2.27 60 36.00 28.26
18 3.24 2.54 63 39.69 31.16
19 3.61 2.82 65 42.25 33.17
20 4.00 3.14 70 49.00 38.49
21 4.41 3.46 75 56.25 44.16
22 4.84 3.80 80 64.00 50.24
24 5.76 4.52 85 72.25 56.72
25 6.25 4.91 90 81.00 63.59
26 6.76 5.30 95 90.25 70.85
28 7.84 6.15 100 100.00 78.50


Advantage:

1. The material of our billet is Q345B, which is similar to A572, GR 50, please refer to the attached comparison document.
2. Our billet is very straight and The surface of our billet is very smooth.
3. We customize radius of the angle to be 3mm, which is most suitable for rail wheel to run.
4. The both end side of this billet was cut by Sawing machine which is very easy for assemble.

Overhead Crane Accessories Square Solid Steel Bar / Hot Rolled Steel Flat Bar
