5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction
5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction
5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction
5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction
5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction
5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction
Specifications
Brand Name :
NANTE
Model Number :
SHA
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Supply Ability :
100000 sets per year
Delivery Time :
1-2weeks
Packaging Details :
CARTON
Max Load Capacity :
100000kg
Sling Type :
Wire Rope
Trolley Speed :
5m/20min
Height :
6/8/9/12/18
Description

Product Description

The low headroom type electric hoist is of exquisite design, superior performance, novel and beautiful appearance. Also, it meets the latest international certification of DIN, FEM and reaches the technical level of similar products overseas. It is suitable for machining, assembly, warehouse and other places of material handling, especially fit for highly restricted site factory.

Low headroom hoist

Load capacity FEM ISO Height Speed Trolley speed H Size C Size
(Kg) 　 　 (m) (m/min) (m/min) (mm) (mm)
1000 4m M7 8/9/12/18 0.8/5.0 5/20 245 385
1260 3m M6 6/9/12/18 0.8/5.0 5/20 245 385
1600 3m M6 6/9/12/18 0.8/5.0 5/20 245 385
11100 4m M7 6/9/12/18 1.3/8.0 5/20 245 385
2000 2m M5 8/9/12/18 0.8/5.0 5/20 245 385
2000 3m M6 8/9/12/18 1.3/8.0 5/20 245 385
2500 3m M6 6/9/12/18 0.8/5.0 5/20 245 385
2500 3m M6 8/9/12/18 1.0/8.3 5/20 245 385
2500 2m M5 6/9/12/18 1.3/8.0 5/20 245 385
3200 2m M5 6/9/12/18 0.8/5.0 5/20 245 385
3200 2m M5 8/9/12/18 1.0/6.3 5/20 245 385
6000 2m M5 8/9/12/18 0.8/5.0 5/20 288 496
5000 2m M5 8/9/12/18 1.8/10 5/20 296 792
6000 3m M6 8/9/12/18 1.3/8.0 5/20 298 792
6300 1Am M4 6/9/12/18 0.8/5.0 5/20 266 495
6300 1Am M4 8/9/12/18 1.3/8.0 5/20 288 496
6300 2m M5 6/9/12/18 1.3/8.0 5/20 266 495
6300 3m M6 6/9/12/18 1.0/8.3 5/20 288 496
8000 1Am M4 8/9/12/18 1.3/8.0 5/20 296 792
11000 3m M6 8/9/12/18 0.8/5.0 5/20 298 792
10000 1Am M4 8/9/12/18 1.0/6.3 5/20 298 792
10000 2m M5 6/9/12/18 0.8/5.0 5/20 296 792
10000 3m M6 8/9/12/18 0.68/4.0 5/20 298 792
12500 1Am M4 8/9/12/18 0.8/5.0 5/20 296 792
12500 2m M5 8/9/12/18 0.6/4.0 5/20 298 792
12500 2m M5 6/9/12/18 0.6/4.0 5/20 296 792

Load capacity FEM ISO Height Speed Trolley speed H Size C Size
(Kg) 　 　 (m) (m/min) (m/min) (mm) (mm)
2000 2m M5 6/9/12/18 0.8/5.0 5/20 230 350
3200 2m M5 6/9/12/18 0.8/5.0 5/20 230 350
5000 2m M5 6/9/12/18 0.8/5.0 5/20 230 350
5000 2m M5 6/9/12/18 0.8/5.0 5/20 230 350
8000 3m M6 6/9/12/18 0.8/5.0 5/20 540 360
10000 1Am M4 6/9/12/18 1.0/6.3 5/20 540 360
10000 2m M5 6/9/12/18 0.8/5.0 5/20 540 360
10000 3m M6 6/9/12/18 0.66/4.0 5/20 540 360
12500 1Am M4 6/9/12/18 0.8/5.0 5/20 540 420
12500 1Am M4 6/9/12/18 1.0/6.3 5/20 540 420
12500 2m M5 6/9/12/18 0.6/4.0 5/20 540 420
16000 2m M5 6/9/12/18 0.66/4.0 5/20 640 480
20000 1Am M4 6/9/12/18 0.66/4.0 5/20 640 480
20000 2m M5 6/9/12/18 0.53/3.4 5/20 640 480
20000 3m M6 6/9/12/18 1.0/4.2 5/20 790 620
25000 1Am M4 6/9/12/18 0.53/3.4 5/20 790 620
25000 2m M5 6/9/12/18 0.8/3.3 5/20 790 620
25000 2m M5 6/9/12/18 1.0/4.2 5/20 790 620
32000 2m M5 6/9/12/18 0.8/3.3 5/20 790 620
32000 2m M5 6/9/12/18 0~4.9 5/20 895 980
40000 1Am M4 6/9/12/18 0~4.9 5/20 895 980
50000 2m M5 6/9/12/18 0~3.2 5/20 895 980
50000 1Am M4 6/9/12/18 0~4.0 5/20 895 980
63000 1Am M4 6/9/12/18 0~3.2 5/20 975 1100
63000 2m M5 6/9/12/18 0~2.4 5/20 975 1100
80000 1Bm M3 6/9/12/18 0~3.8 5/20 1025 1525
100000 1Bm M3 6/9/12/18 0~2.1 5/20 1025 1525

Accessories

Trolley drive unit

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize ConstructionTrinity of high-performance motor, reduction gearbox and brake. Compact structure, excellent performance. Low energy consumption, low noise and eco-friendly design. Variable frequency control, smooth running, low impact and meeting requirements of a variety of speed. Asbestos-free brake disc and its normal service life can be up to one million times. No-wear design, maintenance-free, long service life.

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction

Rope guide

Light weight, good wear resistance, to reduce the wear of wire rope effectively. Prevent wire rope from skipping and loosing to off-groove, and safety first.

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize ConstructionLifting height limiter

Freely adjustable screw lifting height limiter with high precision, wide adjustment range, safe and reliable. Multiple-contact configurations can effectively achieve the function of transition with low and high speed and the stop during the rise and fall.

Drum

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize ConstructionUse the Q345-type seamless steel tube as raw material and process it by numbers of working procedure. Advanced processing methods to ensure concentricity of the drum. The depth of rope groove is in compliance with the FEM standard. High-strength pressing plates and bolts are fastened on the end of the wire rope to ensure the safety of lifting.

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction

Lifting hook group

DIN standard of lifting hook with safety clasp and wire rope sheath Ergonomic design. Forged by the high-strength material of T grade. Accompanied with nondestructive test certification of lifting hook randomly.
