Specifications
Brand Name :
NANTE
Model Number :
HHBB
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Payment Terms :
L/C, T/T
Supply Ability :
100000 sets per year
Delivery Time :
1-2 weeks
Packaging Details :
CARTON
Capacity :
7.5t
Lifting Speed :
1.8/0.6 m/min
Motor Power :
3kw
Control Voltage :
24V/36V/48V
Power Supply :
3-Phase 380V 50Hz
Description

Our company

After 20 years rapid development, NANTE and its parents company ZHONGJIAN Group has grown into a leading integrated solution provider for crane and crane components in China. Dedicated to the research and development of new lifting and handling technologies, we adopt innovative ideas and design in developing new products and services. Backed up by a wealth of industrial experience on lifting industry, we can provide to customer wide range of lifting equipment and components with scientific design, good safety, high performance, efficient operation and low maintenance cost. We are committed to help our clients to reduce investment cost, improve production efficiency, and economize energy consumption.

Parameter

1. Three meters of lifting height and power supply cable as standard accompanies.

2. Extending the load chain is prohibited with additional links.

3. Optional lifting length, push button cord and power supply cable beside standard is available on your request.

4. Canvas chain container are standard accompanies; steel chain containers are available if your lift is more than capacity of the standard container volume.

5. Emergency stop button on the push button switch, push down it, the motor circuit will be cut off.

6. Power voltage: 110V, Single phase, 220V-690V, dual voltage is available. 50Hz and 60Hz are optional.

7. Control voltage: 24V, 36V, 48V are optional.

8. Wireless remote control can be assembled.

Product Description

Model HHBB
7.5-0.3S 7.5-0.3D
Capacity(Ton) 7.5 7.5
Lifting speed(m/min) 1.8 1.8/0.6
Motor Power(kw) 3.0 3.0/1.0
Rotation speed(r/min) 1440 2880/960
Insulation Grade F class
Travelling speed(m/min) Slow 11m/min & Fast 21 m/min
Power Supply 3P-380-50Hz
Control Voltage 24V/36V/48V
No. of Load Chain 3
Spec. of Load Chain φ11.2
Net Weight(kg) 176 215
I-Beam(mm) 125-178

Model Unit(mm)
H A B D E R T
HHBB7.5-0.3S 1200 615 295 505 320 142 231
HHBB7.5-0.3D 1200 670 313 505 320 142 231

Advantages

1. Combine all the desirable features found in various other similar products into one revolutionary creation.

2. Maintenance-free design is safe and reliable to use,

3. Compact design comes in small size, which allows ease of carrying around.

4. Exceptional performance

5. Maximum return on investment, great price to performance ratio.

6. Multiple patents granted for one innovative entertainment hoist.

7. Available with a number of configurations to solve various applications.
