120 m / min Travel speed C Track Festoon System for Crane / Galvanized Steel Festoon Cable Trolley
120 m / min Travel speed C Track Festoon System for Crane / Galvanized Steel Festoon Cable Trolley
Specifications
Brand Name :
NANTE
Model Number :
C32-70
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
usd2-5/pc
Payment Terms :
L/C, T/T
Supply Ability :
usd100000/year
Delivery Time :
7 working days
Packaging Details :
carton
Material :
Galvanized steel
Wheel :
Ball bearing
Temperature :
-30-+100 degree
Travel speed :
120m/min
Color :
can be customized
Description

Detailed Product Description

C Track Festoon System for Crane, Galvanized Steel Conductor Rails With Brass Dowel , C Rail and Trolley, Stretched Wire Festoon System, Festoon Cable Trolley, Festoon Cable System.

Detailed Product Description

Festoon System can hold conductor cables and hoses (hydraulic and pneumatic applications) for delivering power & control to mobile equipment in a safe, efficient and maintenance free method.

The C-track system is one of the most versatile festooning techniques available. It is an all-purpose system suited for either indoor or outdoor use under a broad range of operating conditions in a mild environment condition.

120 m / min Travel speed C Track Festoon System for Crane / Galvanized Steel Festoon Cable Trolley

Type Towing Trolley End Trolley Middle Trolley Round Cable Trolley
Wheels

Ball bearings, hardened, galvanized

Temperature resistance Lub. grease of wheels: -30°C to +100°C

Max. travelling speed: 120m/min.

Ball bearings, hardened, galvanized

Temperature resistance Lub. grease of wheels: -30°C to +100°C

Travelling speed: ca 120m/min.
Material

Carrier body: steel, galvanized
Support saddle: steel, galvanized
Bumper: neoprene
Dowel: brass
Hardware: galvanized

Temperature: resistance: -30°C to +100°C

 Carrier body: steel, galvanized
Clamp: steel, galvanized
Sling: nylon
Dowel: brass
Hardware: galvanized
Max. cable load Max. 22kg per carrier Max. 22kg per carrier Max. 25kg per carrier Max.22kg per carrier
Dim. Of cable (mm) Max. 75w×32δ Max. 75w×32δ Max.75w×32δ Max. D=50mm/D=80mm/D=160mm
Weight (kg) 0.55 0.32 0.31 0.29
