4m / 6m C Track Festoon System C32 Trolley Cable Holding System
4m / 6m C Track Festoon System C32 Trolley Cable Holding System
Specifications
Brand Name :
Nante
Model Number :
C32
Certification :
ISO9001, CE, CCC
Place of Origin :
CHINA
MOQ :
100 Metres
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
Within 14 days
Packaging Details :
seaworthy packing
Model Number: :
C32
Standard Length: :
4m or 6m
Cable Load: :
max.503kg
Temperature: :
-30℃ to +100℃
Travel Speed: :
<160m/min
C track Size: :
63mm*63mm*4.0mm
Material: :
Galvanized steel
Description

Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: NANTE
  • Model Number: C32
  • Material: Galvanized steel
  • C track Size: 32mm*30mm*1.5mm
  • Standard Length: 4m or 6m
  • Travel Speed: <120m/min
  • Temperature: -40℃ to +125℃
  • Cable Load: <120kg

Packaging & Delivery

Packaging Details: Naked, Wooden case or Carton
Delivery Detail: Within 10days

Specifications

1.C Track and Trolley Cable Holding System
2.Certification: CCC, ISO, CE
3. For cranes, stacking system

C Track and Trolley Cable Holding System, Power Supply Festoon Cable Trolley C32, Festoon Cable Trolley C32, Galvanized Steel Conductor Rails With Brass Dowel , C Rail and Trolley, Stretched Wire Festoon System, Festoon Cable Trolley, Festoon Cable System.

Detailed Product Description

Festoon System can hold conductor cables and hoses (hydraulic and pneumatic applications) for delivering power & control to mobile equipment in a safe, efficient and maintenance free method.

The C-track system is one of the most versatile festooning techniques available. It is an all-purpose system suited for either indoor or outdoor use under a broad range of operating conditions in a mild environment condition.

Application

C-rail systems applications: crane manufacturing, hoist units, transport systems, special engineering, stacking systems, conveyor system, etc. C-rails are available in zinc-coated and stainless steel version (program 230 to 240). Special versions are available for explosion-proof areas.

Design features:

Compact arrangement, corrosion resistance and simple assembly are its essential features. Easy for transportation and installation

Technical Parameters

4m / 6m C Track Festoon System C32 Trolley Cable Holding System

Type

C32*30*1.5

C40*40*2.0

C63*63*4.0

C30*28*1.5

Material

Galvanized steel / Except C63

Weight kg/m

1.19

2.00

5.98

1.03

Technical data

A

32

40

63

30

B

30

40

63

28

C

12

13

18

10

6

1.5

2.0

4.0

1.5

Spacing

Max. Cable Load

1.5m

89kg

188kg

503kg

70kg

2.0m

51kg

103kg

425kg

36 kg

2.5m

39kg

73kg

302kg

22kg

3.0m

23kg

49kg

195kg

-

4.0m

-

28kg

85kg

-

4m / 6m C Track Festoon System C32 Trolley Cable Holding System

Type

Towing Trolley

End Trolley

Middle Trolley

Round Cable Trolley

Wheels

Ball bearings, hardened, galvanized

Temperature resistance Lub. grease of wheels: -30°C to +125°C

Max. travelling speed: 160m/min.

Ball bearings, hardened, galvanized

Temperature resistance Lub. grease of wheels: -30°C to +125°C

Travelling speed: ca 120m/min.

Material

Carrier body: steel, galvanized
Support saddle: steel, galvanized
Bumper: neoprene
Dowel: brass
Hardware: galvanized

Temperature: resistance: -30°C to +100°C(ABS Saddle 80°C)

Carrier body: steel, galvanized
Clamp: steel, galvanized
Sling: nylon
Dowel: brass
Hardware: galvanized

Max. cable load

Max. 25kg per carrier

Max. 25kg per carrier

Max. 30kg per carrier

Max.22kg per carrier

Dim. Of cable (mm)

Max. 75w×32δ

Max. 75w×32δ

Max.75w×32δ

Max. D=50mm/D=80mm/D=160mm

Weight (kg)

0.61

0.39

0.415

0.29
