Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley
Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley
Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley
Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley
Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley
Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley
Specifications
Brand Name :
NANTE
Model Number :
WF-30/40
Certification :
Certification
Place of Origin :
CHINA
MOQ :
1pc
Supply Ability :
1000000 pcs per year
Delivery Time :
1-2 weeks
Packaging Details :
CARTON
Wheels :
Plastic
Max. Travel Speed :
120m/min
Material :
ABS
Max.cable load :
max.10 kg/trolley
Dia. of Cable :
D=φ40mm
Weight :
0.18kg
Description

Detailed Product Description

Crane& Hoist Steel Wire Cable Trolley Festoon System , Galvanized Steel Conductor Rails With Brass Dowel, Rope and Trolley, Stretched Wire Festoon System, Festoon Cable Trolley, Festoon Cable System.

Steel wire trolley applied to light load mobile power supply device, easy to install, low cost.

Festoon System can hold conductor cables and hoses (hydraulic and pneumatic applications) for delivering power & control to mobile equipment in a safe, efficient and maintenance free method. This festoon system is one of the most versatile festooning techniques available. It is an all-purpose system suited for either indoor or outdoor use under a broad range of operating conditions in a mild environment condition.

NANTE supply full line of beam trolley,

  1. For Straight or Curver Beam
  2. For IPN Beam or H Beam or I-Beam
  3. For Normal Working Condition or Corrosivity
  4. For Light or Heavy Duty Working
  5. For One or Two or Three Foor Cables

Specifications

1. Crane& Hoist Steel Wire Cable Trolley Festoon System

2. Delivering power& control to mobile equipment

3. Safe, convenient

Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley

Application

Steel Wire systems applications: crane manufacturing, hoist units, transport systems, special engineering, stacking systems, conveyor system, etc, suitable for small cable loads.

Design features:

Compact arrangement, corrosion resistance and simple assembly are its essential features. Easy for transportation and installation

Technical Parameters

Firm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End TrolleyFirm And Flexible Wire Steel Festoon Accessories For Round Cable Middle / End Trolley

Type Max. cable load Dia. Of Cable(mm) Weight(kg)
WRMT-30 Max.8kg/trolley D=φ30mm 0.17
WRMT-40 Max.10kg/trolley D=φ40mm 0.18
WRET-30 Max.8kg/trolley D=φ30mm 0.06
WRET-40 Max.10kg/trolley D=φ40mm 0.07
Wheels Plastic
Max Travel Speed 120m/min
Material ABS
Temperature -30℃~+80℃
