Specifications
Brand Name :
NANTE
Model Number :
NANTE-03
Certification :
ISO
Place of Origin :
CHINA
MOQ :
50M
Price :
8.89-13USD/PC
Payment Terms :
L/C, T/T
Supply Ability :
500M/DAY
Delivery Time :
7 days
Packaging Details :
plywood carton
Material :
copper and PVC
poles: :
3 poles and 4 poles
Stand length: :
4M
Application :
crane
max voltage: :
600V
Current range: :
35A-80A-170A
Description

low price sliding line busbar power pipe enclosed conductor system for overhead crane

  • Brief introduction/

Powerail Enclosed conductor rail system is a powerail, protectedfrom contact (IP 23), For indoor and outdoor plants. They are conductor lines in a rigid greeen PVC housingwith differentcopper cross sections for rated currents of 35 - 240A

The current collectors, running in ball bearings, are guided bythe housing.

The main is transferred by springstored carbon brushes.Type HFP-P: not include Sealing strip, with factorymounted flat copper band and bolted- -operated plug connectors .

Product Description
Type Poles

conductor

cross section (mm2)

max current (A)

 leakage -distance (mm) max voltage (V) resistance weight(kg) (order-NO)
HFP56-4-8/35 4 8 35 35 600 1.944 2.09 560002
HFP56-4-10/50 4 10 50 35 600 1.656 2.16 560003
HFP56-4-12/65 4 12 65 35 600 1.321 2.23 560004
HFP56-4-15/80 4 15 80 35 600 1.137 2.30 560005
HFP56-4-20/100 4 20 100 35 600 1.011 2.43 560006
HFP56-4-25/120 4 25 120 35 600 0.713 2.56 560007
HFP56-4-35/140 4 35 140 35 600 0.522 2.95 560008
HFP56-4-50/170 4 50 170 35 600 0.337 3.25 560009
HFP56-4-70/210 4 70 210 35 600 0.265 3.85 560010
HFP56-4-80/240 4 80 240 35 600 0.223 4.16 560011
