5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
Specifications
Brand Name :
OUCO
Model Number :
OUCO-TB-4T5M
Certification :
ISO9001/CE/ABS/CCS/BV
Place of Origin :
Jiangsu, China
MOQ :
1 set
Supply Ability :
100 sets per year
Delivery Time :
45 days
Packaging Details :
Shipping Container/Wood Crate/nude
Slewing angle :
360 degree free
Boom type :
stiff/fixed
Material :
Steel
Usage :
marine deck
Luffing :
no
Luffing angle :
~70 degree
Max. Working radius :
5m
Power :
electric
Price :
Negotiation
Description

5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane

Product Description

The deck crane is a kind of ship's hoisting equipment usually set in the cabin deck which contents high technology of electricity, liquid, machine integration of deck. With the advantageof easy manipulation, impact resistance, good performance,safety and reliability, it can make a good use of the limited space of port, yard and other places. It has high working efficiency and good adaptability to the goods, especially for the dry bulk cargo handling.

SB series crane: End User Advantages:

1. Compact design

2. Small footprint

3. Delivered as one complete unit ready for installation to vessels

4. Easy access for periodic maintenance, service and repair

5.24 hours after sales searvices support.

Specification

SWL 4T@5M
MAX WORKING RADIUS 5m
MIN WORKING RADIUS 2m
HOISTING SPEED 0~10m/min
HOISTING HEIGHT 20m
SLEWING SPEED ~0.8r/min
SLEWING ANGLE 360°
LUFFING TIME ~ 45s
WORKING CONDITION

TRIM ≤2°

HEEL ≤5°

ELEC-MOTOR

 Y160K-4-H
POWER 15kw
Speed 1460r/min
POWER RESOURCE AC415V/50HZ
PROTECT CLASS IP56
INSUKATE CLASS F
WORKING TYPE S1

GA drawing

5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane

Details

5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane

Our Company

With years of experience, the OUCO Marine Group has its own designing team and manufacturing factory, excellent European management who has 47 years of experience on offshore business, which also provides after sales services overseas.

Our production line covers marine and offshore knuckle boom crane, telescopic crane, stiff boom crane, non-standard steel structure, more environmental-friendly operations and also truck crane with the range from 15t to 150t.Port industry which includes cranes, hoppers and grabs.

OUCO Machinery can build any type of handling equipment, according to our own design, but also according to provided designs.

We build products according to any certification requested by the client and are able to build them for working in, and under extreme heavy circumstances for working tempertures of - 40C accordingly.
