500T Crawler Crane Main Boom 60m For Wind Farm Equipment Installation
500T Crawler Crane Main Boom 60m For Wind Farm Equipment Installation
Specifications
Brand Name :
ZOOMLION
Model Number :
ZCC5800
Place of Origin :
China
MOQ :
One Crane
Price :
Negotiable Price
Payment Terms :
L/C,T/T
Supply Ability :
Supply According to Customer Needs
Delivery Time :
According to Order Confirmation
Packaging Details :
Packing According to Customer Requirements
Maximum Lifting Speed :
120m/min
Maximum Travel Speed :
1.5km/h
Maximum Lifting Height :
108m
Maximum Gradeability :
30%
Boom Length :
18-96m
Maximum Lifting Capacity :
500 tons
Fuel Tank Capacity :
600L
Jib Length :
12-36m
Model :
XGC500
Maximum Wind Speed For Operation :
12m/s
Maximum Lifting Radius :
100m
Engine Power :
298kW
Description

500T Crawler Crane For Wind Farm Equipment Installation

ZCC5800 Crawler Crane Rated Lifting Capacity Manual


Chapter 5 Luffing Jib Working Conditions

Main boom 54m Rear weight 160t Vehicle weight 40t 360° Full slewing Main boom elevation angle 85°

Radians (m)

Jib length(m)

Radians (m)

24

30

36

42

48

54

60

66

72

16

118

16

18

106

102

18

20

95.4

91.9

88.8

86.3

20

22

86.8

83.6

80.7

78.4

75.7

22

24

79.5

76.6

73.8

71.9

69.3

67.3

24

26

73.3

70.5

68

66.3

63.9

62.1

59.7

58

26

28

67.8

65.4

62.9

61.3

59

57.5

55.1

53.6

51.5

28

30

61.8

60.8

58.5

57

54.8

53.3

51.2

49.7

47.7

30

32

56.3

54.6

53.2

51.1

49.7

47.6

46.2

44.3

32

34

51.8

51.1

49.7

47.7

46.4

44.4

43.1

41.2

34

36

47.8

47.4

46.7

44.8

43.5

41.6

40.3

38.5

36

38

44

43.9

42

40.9

39

37.8

36

38

40

40.9

40.8

39.6

38.4

36.6

35.5

33.8

40

44

35.7

35

34.2

32.5

31.5

29.8

44

48

31.3

30.7

30.4

29

28

26.4

48

52

27.1

26.9

26

25

23.5

52

56

23.9

23.1

22.5

21

56

60

20.5

20.2

18.8

60

64

18.2

17.9

16.8

64

68

15.9

15.1

68

72

13.4

72

76

11.8

76

Main boom 60m Rear weight 160t Vehicle weight 40t 360° Full slewing Main boom elevation angle 85°

Radians (m)

Jib length(m)

Radians (m)

24

30

36

42

48

54

60

66

72

16

114

16

18

101

97.9

18

20

91.8

88.5

85.3

20

22

83.6

80.6

77.7

75.5

72.8

22

24

76.6

73.8

71.1

69.3

66.7

64.8

24

26

70.7

68.1

65.6

63.9

61.4

59.7

57.3

26

28

65.6

63.1

60.8

59.2

56.8

55.3

53.1

51.5

49.4

28

30

61.1

58.7

56.5

55

52.8

51.4

49.2

47.7

45.7

30

32

54.8

52.7

51.3

49.2

47.9

45.8

44.4

42.4

32

34

51.4

49.3

48

46

44.7

42.7

41.4

39.5

34

36

47.6

46.3

45

43.1

41.9

40

38.8

36.9

36

38

43.6

42.4

40.6

39.4

37.5

36.3

34.6

38

40

40.6

39.9

38.2

37

35.2

34.1

32.4

40

44

35.4

34

33

31.3

30.2

28.6

44

48

31

30.4

29.6

27.9

26.9

25.3

48

52

26.9

26.6

25

24

22.5

52

56

23.7

22.5

21.5

20.1

56

60

21

20.3

19.4

17.9

60

64

18

17.4

16

64

68

15.7

14.3

68

72

13.9

12.8

72

76

11.4

76

Main boom 30m Rear weight 160t Vehicle weight 40t 360° Full slewing Main boom elevation angle 75°

Radians(m)

Jib length(m)

Radians (m)

24

30

36

42

48

54

60

66

72

22

88.7

22

24

79

24

26

71

70.2

26

28

64.3

63.5

62.6

28

30

58.7

57.9

57.1

56.7

30

32

53.7

53.1

52.3

51.9

32

34

49.2

48.9

48.1

47.8

46.9

34

36

45.2

44.5

44.2

43.3

42.8

36

38

41.9

41.3

41

40.1

39.7

38.7

38

40

38.4

38.1

37.3

36.8

35.8

35.3

40

44

33.4

33.3

32.4

32

31.1

30.6

29.6

44

48

29.2

28.5

28.1

27.1

26.7

25.7

48

52

25.1

24.8

23.9

23.4

22.5

52

56

22.2

22

21.1

20.6

19.7

56

60

19.5

18.6

18.2

17.3

60

64

16.5

16.1

15.3

64

68

14.6

14.3

13.4

68

72

12.6

11.8

72

76

10.3

76

80

9

80

Main boom 36m Rear weight 160t Vehicle weight 40t 360° Full slewing Main boom elevation angle 75°

Radians (m)

Jib length(m)

Radians(m)

24

30

36

42

48

54

60

66

72

24

77.3

24

26

69.5

26

28

63

62

28

30

57.4

56.6

55.6

30

32

52.6

51.9

50.9

50.5

32

34

48.4

47.8

46.9

46.5

45.5

34

36

44.2

43.3

43

42

36

38

40.9

40.2

39.9

38.9

38.4

38

40

38

37.4

37.1

36.1

35.7

34.6

40

44

32.5

32.3

31.4

31

30

29.5

28.2

44

48

28.4

27.5

27.1

26.2

25.7

24.7

48

52

25

24.3

23.9

23

22.5

21.5

52

56

21.5

21.2

20.2

19.8

18.8

56

60

18.8

17.9

17.4

16.5

60

64

16.6

15.8

15.4

14.5

64

68

14

13.6

12.7

68

72

12

11.2

72

76

10.5

9.7

76

80

8.4

80
