CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC
CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC
CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC
CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC
Specifications
Place of Origin :
Guangdong, China
Brand Name :
CREATALL
Supply Ability :
10000 Piece/Pieces per Day
MOQ :
10pcs
Price :
negotiable
Delivery Time :
5-8 work days
Model Number :
CA-0518
Model :
CA-0518
Type :
integrated circuit
Input voltage :
300-450V DC
Output voltage :
36-180V DC
Power :
45W
Port :
shenzhen port.guangzhou port
Description

CA-0518 19-60 Inch LED Universal Backlight Constant Current Board 220V Or 110V AC Input 300-240V DC Applicable

Product Description:

  • product name: led backligth constant current board
  • prodcut model: CA-0518
  • input voltage: 300-450V DC
  • output voltage: 36-180V DC
  • power: 45W
  • apply: universal 19-60inch
  • product size: 115*50mm
  • product weigth: 355g

Interface specification

  • ON Connects to the signal control pin(Voltage range about 3.3V)
  • ADJ Connects to the brightness control foot(Voltage range 0-3.3V)
  • ADJ, brightness adjustment, if the default value is 0V, the output voltage to the light bar is the highest; When the voltage of the ADJ pin increases, the voltage output to the light bar decreases, and the light bar becomes dimmer. ADJ is to use voltage to control the output voltage to achieve the brightness control bar. All constant flow plate and high pressure plate ADJ. are the same
  • GND Connects (cold) ground

CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC

CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC

CA-0518 LED Universal Backlight Constant Current Board 19-60 Inch 220V 110V AC
