SASPG Stainless Steel Cryogenic Nitrogen Plant Generator 10000Nm3/H
SASPG Stainless Steel Cryogenic Nitrogen Plant Generator 10000Nm3/H
SASPG Stainless Steel Cryogenic Nitrogen Plant Generator 10000Nm3/H
SASPG Stainless Steel Cryogenic Nitrogen Plant Generator 10000Nm3/H
Specifications
Brand Name :
SASPG
Model Number :
High-purity Nitrogen Air Separation Plant, 10000Nm3/h
Certification :
ASME/CE/GB
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
50 Sets / Year
Delivery Time :
8months-18months
Packaging Details :
container, wooden case ,bulk
Condition :
New
Material :
Stainless Steel, Carbon Steel, Aluminum
Products :
LIN, Gasous Nitrogen
Purity :
99.999%
Warrenty :
12month,24month,18month
Application :
Petrochemical, Medical, Lithium Battery New Energy, Petroleum & Metallurgy Industry
Description

High-purity Nitrogen Air Separation Plant with Cpacity of 10000Nm3/h

SASPG is the largest oxygen & nitrogen liquefier manufacturer in China. The capacity of the liquefiers ranges from 50TPD to 1000TPD.

SASPG is the first and currently the largest company in China engaged in designing and manufacturing natural gas (associated gas) liquefaction & separation plants and has developed the natural gas liquefaction plant with a mixed refrigerant process, with expander-made refrigeration, with de-nitrification process, and with heavy hydrocarbon washing process. A maximum extend localized natural gas liquefaction plant with capacity of 600,000 Nm3/d has been put into operation, and the erection of a natural gas liquefaction plant with a capacity of 2,000,000Nm3/d has been completed.

SASPG has the first-class international analysis/design soft wares, which have already been successfully used in the product design. Now we can design and manufacture the air separation plants with the capacity up to 63,000 Nm3/h. and have ability to develop the air separation plants with the capacity up to 80,000~120,000 Nm3/h and 1000 Nm3/h to 50000Nm3/h high-purity nitrogen air separation.

The air separation plant applies the advanced air separation technology with normal-temperature adsorption..

A detailed brochure is attached with our offer which includes our company organization, structures and capabilities, a brief introduction to SASPG follows:

  • SASPG was established in 1966
  • Plant building covered area – 321715 m2
  • Staff - 3000
  • Total Assets – 334 Million USD
  • Annual Turnover – 300 Million USD
  • Production Capacity – 50000 Tons
  • Plant capacities – 50 Nm³/hr up to 100000 Nm³/hr
Product Output(Nm³/h) Purity (volume) Pressure Bar(g) (battery limit)
GAN 10000 O2≤3ppm 8.5
LIN 800 O2≤3ppm to LIN Tank

(1) Nm³/h means volume flow under 0℃, 0.1013MPa (A), which is called flow under standard state;

(2) Plant can be stably & reliably operate during 75 -100% of processing feed air;

SASPG Stainless Steel Cryogenic Nitrogen Plant Generator 10000Nm3/H

SASPG Stainless Steel Cryogenic Nitrogen Plant Generator 10000Nm3/H
