Specifications
Brand Name :
Yong sheng dredger
Model Number :
YSCSD500H-15
Certification :
ZC
Place of Origin :
china
MOQ :
1
Price :
Price: 300000-1200000 US Dollars
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 sets per year
Delivery Time :
50 days
Packaging Details :
Bulk transport
Discharge Distance :
2000m
Cutter Power :
660kW
Pump Power :
2647kW
Maximum Dredging Depth :
1-15Meter
Package Gross Weight :
550T
Total Height :
8m
Front Plate Thickness :
20mm
Plc :
Siemens
Diesel Engine Brand :
WEICHAI
Water flow :
4000m³
Solid capacity :
600m³
model :
18 inch
Description

model 18 inch Bucket wheel dredger working at the seaside can remove 500 cubic meters of silt per hour

1.Cutter suction dredger is the one of the best popular dredging machinery . full hydraulic automatic to drive the main equipment . such as cutter

head . spud and all kinds of winch so on . famfous diesel engine brand from the abroad ( Germany. Aemerica)to provide the power for the

whole dredger , such as river sand pump . hydraulic oil pump , generator and water pump so on. all dredger is made by the marine steel can

improve the dredger working life . whole dredger use the Siemens PLC to control to reach the full automatic . recently years cutter suction

dredger is more and more used all kinds dredging project

The company's products cover various types and specifications of dredgers, including cutter suction dredgers, rake suction dredgers, chain bucket dredgers,aquatic weed harvester etc. The company adheres to the business philosophy of "quality first, customer first", with the aim of integrity, innovation, and win-win, and has established long-term and stable cooperative relationships with customers.

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

2.Technical specifications for YSCSD650 solid capacity 900 cbm/h hydraulic cutter suction dredger

Water flow 7,000 m3/h
Solid capacity 1400 cbm/h
Max. dredging depth 45° 18 m
Discharge distance 1,800 m
LOA 50 m
Dredger after assembly 50*11*3.2m Length* width* depth
Dredger structure Dismantle type and can be assembly in working site
Average draught 2 m
Diameter discharge pipe 650 mm/26 inch
Main Engine 2,647 kw WEICHAI
Rotate speed 1800 r/min
Auxiliary engine power 1000 kw WEICHAI engine
Generator 50 kw
Hydraulic cutter power 660 kw
Total power 3697 kw

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

3. Packaging
1. Disassemble the detachable components and mark them properly.
2. Use appropriate packaging materials to wrap and secure the components to prevent collision and damage.
2, Transportation
1. Choose a suitable transport vehicle or vessel based on the size and weight of the dredger.
2. Ensure that the transportation vehicle has sufficient load-bearing capacity and stability.
During transportation, pay attention to the speed and smoothness of driving to avoid severe bumps.

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

4. On site installation of cutter suction dredgers. We will send excellent technicians to guide the installation on site, and after the installation is completed, we will also provide training to on-site personnel until they become proficient in the operation

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

5. Special requirement for cutter suction dredger can be custom building

Standard Model list for hydraulic cutter suction dredger
Model Inch Diameter pipe Water flow Solid capacity Total power Dredging depth

Discharge

distance
YSCSD150 6 Inch 150 mm 260 m3/h 30 cbm/h 102 KW 4 m 600 m
YSCSD200 8 Inch 200 mm 600 m3/h 80 cbm/h 213 KW 6 m 800 m
YSCSD250 10 inch 250 mm 1,000 m3/h 160 cbm/h 367 KW 8 m 1,100 m
YSCSD300 12 inch 300 mm 1,500 m3/h 240 cbm/h 591 KW 10 m 1,100 m
YSCSD350 14 inch 350 mm 2,400 m3/h 360 cbm/h 971 KW 12 m 1,200 m
YSCSD400 16 Inch 400 mm 3,000 m3/h 500 cbm/h 1,057 KW 14 m 1,400 m
YSCSD450 18 Inch 450 mm 3,500 m3/h 700 cbm/h 1,462 KW 15 m 1,500 m
YSCSD500 20 Inch 500 mm 3,800 m3/h 760 cbm/h 1,648 KW 15 m 1,600m
YSCSD600 24 Inch 600 mm 6,000 m3/h 900 cbm/h 2,511 KW 15 m 1,800 m
YSCSD650 26 Inch 650 mm 7,000 m3/h 1,400 cbm/h 3,705 KW Max.18m 1,800m

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

We also have supporting facilities for the cutter suction dredger, such as discharge pipes, pipeline floats, and anchor boats that work with the dredger

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

18inch Bucket Wheel Cutter Dredger Boat At The Seaside Can Remove 500m³ Of Silt Per Hour

Any interested pls advise
