45 Mm Forming Depth Plastic Lid Forming Machine PET PS PVC Sheet Material
45 Mm Forming Depth Plastic Lid Forming Machine PET PS PVC Sheet Material
45 Mm Forming Depth Plastic Lid Forming Machine PET PS PVC Sheet Material
45 Mm Forming Depth Plastic Lid Forming Machine PET PS PVC Sheet Material
Specifications
Place of Origin :
Zhejiang, China (Mainland)
Model Number :
HLD-420W
Certification :
CE
Price :
Negotiable
MOQ :
1 Set/Sets
Processing Type :
Plastic Thermoforming Machine
Condition :
New
Product Type :
Plastic Cup
Voltage :
380V
Dimension(L*W*H) :
2500*1000*1650
Weight :
1000KG
Warranty :
One Year
Sheet material :
PET PS PVC
Sheet thickness :
0.1mm to 1mm
Sheet feeding :
by motor power
Max forming area :
450x160mm
Max forming depth :
45mm
Cutting speed :
15 to 45times/min
Description

Lid Forming Machine Plastic

After-sales Service Provided:Engineers available to service machinery overseas

Main technical parameters:

Cutting Frequency 15--50times/mins
Power 380v/220v/50HZ
Stroke adjustable range 50--180mm
Max.Forming Depth 30mm
Max.Forming Area 420×180mm
Capacity
Motor Power 1.5kw
Consumption >0.4m3/min
Pressure 0.4--0.7mpa
Overall Dimensions 2500×1000×1650mm
Weight 1200kg

45 Mm Forming Depth Plastic Lid Forming Machine PET PS PVC Sheet Material

Main features:

1. The machine is designed and manufactured by the standard of “GMP” in medical industry and “QS” in food industry.

2. This machine can do forming, punching and blanking at the same time to avoid the cross-contamination of product.

3. The forming heating plate can open and close automatically, also can delay to start, so as to control and lower the waste of the material during the production.

4. Easy to replace the mould, application to different specifications of products.

5. Design the mould according to customer’s requirements.

6. Applicable projects: the material of HIPS, PVC, PET, PS.
