Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area
Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area
Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area
Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area
Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area
Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area
Specifications
Place of Origin :
Zhejiang, China (Mainland)
Model Number :
HLD-450W
Certification :
CE
Price :
Negotiable
MOQ :
1 Set/Sets
Processing Type :
Plastic Thermoforming Machine
Condition :
New
Voltage :
380V
Dimension(L*W*H) :
2500*1000*1650
Weight :
1000KG
Warranty :
One Year
After-sales Service Provided :
Engineers available to service machinery overseas
Sheet material :
PET PS PVC
Sheet thickness :
0.1mm to 1mm
Sheet feeding :
by motor power
Max forming area :
450x300mm
Max forming depth :
45mm
Cutting speed :
15 to 45 times/min
Description

HLD-450W Automatic Plastic Plate Forming Machine

Main technical parameters:

Cutting Frequency 15--50times/mins
Power 380v/220v/50HZ
Stroke adjustable range 50--180mm
Max.Forming Depth 30mm
Max.Forming Area 450×260mm
Capacity
Motor Power 1.5kw
Consumption >0.4m3/min
Pressure 0.4--0.7mpa
Overall Dimensions 2500×1000×1650mm
Weight 1200kg


Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area

Automatic Plastic Cup Plate Forming Machine 450 × 260 Mm Forming Area

Main features:

1. The machine is designed and manufactured by the standard of “GMP” in medical industry and “QS” in food industry.

2. This machine can do forming, punching and blanking at the same time to avoid the cross-contamination of product.

3. The forming heating plate can open and close automatically, also can delay to start, so as to control and lower the waste of the material during the production.

4. Easy to replace the mould, application to different specifications of products.

5. Design the mould according to customer’s requirements.

6. Applicable projects: the material of HIPS, PVC, PET, PS.
