2800W Anti Rust Small Table Plate Edge Beveling Machine , Plate Beveler
2800W Anti Rust Small Table Plate Edge Beveling Machine , Plate Beveler
2800W Anti Rust Small Table Plate Edge Beveling Machine , Plate Beveler
2800W Anti Rust Small Table Plate Edge Beveling Machine , Plate Beveler
Specifications
Brand Name :
Wellnit
Model Number :
PB-10D
Certification :
ISO9001
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30 sets a month
Delivery Time :
Within 7days after we received 100% payment
Packaging Details :
Plywood
Power :
AC 380V 50Hz
Total :
2800W
Net Weight :
80Kg
Bevel Width :
1-18mm
Clamp Thickness :
2-40mm
Description

2800W Anti Rust Small Table Plate Edge Beveling

Machine , Plate Beveler

1. Feed torque is improved again,More stable processing performance,The smooth finish of the groove

reaches Ra3.2-6.3

2. The groove angle of the equipment can be adjusted freely between 30° and 60°.

3. easy to use,Easy to learn,Ordinary workers can operate multiple devices at the same time

4. Single maximum slope width 10mm,Up to 18mm multiple times

5. Milling cold working method,The processed groove surface is not oxidized,Stainless steel groove can be

welded without pickling

6. Can be processed for small and medium plates,Knife tray with 4 blades,Each group can process 800-

1200m,Very low consumables

2800W Anti Rust Small Table Plate Edge Beveling Machine , Plate Beveler

Main performance of the product

PB-10D small table plate milling machine.The finish of the groove is as

high as Ra 3.2-6.3,and the machine is suitable for high hardness material

such as carbon steel,stainless steel,aluminum alloy and other materials.

It includes groove processing for high degree of smoothness of beveling

machine.

2800W Anti Rust Small Table Plate Edge Beveling Machine , Plate Beveler

Technical Parameter

PB-10D
Power Supply AC 380V 50HZ
Power 2600W
Spindle Speed 1440r/min
Feed Speed 0~1500mm/min(Adjustable)
Bevel Width 1~18mm
Maximum Milling Width 10mm
Bevel Angle 15°~75°(Adjustable)
Clamp Thickness 2~40mm
Clamp Width >20mm
Net Weight 80Kg
Processing Materials Carbon Steel, Stainless Steel, Aluminium Alloy, Etc

The product description

The chamfered beveling machine developed for small-sized plates is equipped with high-strength

polyurethane as the pressure wheel, which can realize continuous rolling compaction, and the high-

efficiency and stable processing can be realized for the bar plate and the small plate. The small size of the

plate is more suitable, and the pb-10d groove with its strong power and high efficiency has been highly

praised by many customers, with its smooth and clean surface and high efficiency and convenient

movement.

This machine mainly USES the principle of milling, milling the edge of the steel plate according to the

desired Angle, so as to obtain the necessary groove for welding. Applicable to common structural steel

, stainless steel, cast iron, hard plastic, non-ferrous metals and other materials! The flat beveling machine

is chamfered on the end face before welding

The special tool of groove solves the defects such as improper Angle, rough slope surface and loud

working noise of operation process such as flame cutting and grinding by grinding machine

, can automatically walk according to the material edge automatically, this machine has the adjustment

Angle convenient, the operation convenient, the unit time efficiency is high, the environmental protection

has the operation simple, the Angle standard, the surface is smooth.

Product tags

plate edge beveling machine

,

plate beveling machine

,

how to bevel steel plate
