Specifications
Brand Name :
GEZHI or OEM
Model Number :
3-port optical circulator ABS box
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs per month
Packaging Details :
Paper box
Package :
ABS box
Ports :
3 Ports
Pigtail Length: :
1m Or Customized
Connector :
SC/FC/LC/ST
Wavelength :
1310±30 Or 1550±30 Or 1585±30
Application :
FTTH
Warranty :
3years
Description

High Reliability & Stability 3 Ports Fiber Optical Circulator ABS box With SC Connector

Product Description

Gezhi's Optical circulators have many applications in optical circuits and optical communication systems for redirecting bidirectional optical signals into different ports.

This feature is very important to optical bidirectional transmission and communication.Usually, it is used for optical transceiver, FBG( fiber Bragg grating) filter and optical amplifier.

Applications
Add-Drop Multiplexing

Coupling In-Line Chromatic Dispersion Compensation Devices

Fiber Sensors
Bidirectional Pumping

Bidirectional Signal Transmission Systems

Features
Low Insertion Loss

High Channel Isolation

Cost Effective

Compact Package

Low PDL
High Reliability & Stability

Specification

Brand Gezhi
Package ABS box
Configuration Port 1 to Port 2 to Port 3
Operation Wavelength (nm) 1310±30 or 1550±30 or 1585±30
Isolation (dB) Typical 0.6
Maximum 0.8
Typical Isolation (dB) ≥50
Minimum Isolation (dB) ≥40
Cross Talk (dB) ≥50
Polarization Dependent Loss (dB) <0.15
Polarization Mode Dispersion <0.1
Return Loss(dB) ≥50
Power Handling (mW) 500
Opterating Temperature (℃) -10~+75
Package dimension (mm) Φ5.5xL50 or Φ5.5xL63

Application Diagram

As the picture shows: A Circulator is located at both ends of the fiber. Each Circulator functions to add a signal in one direction while removing the signal in the other. See the example to the left.

Circulator can be used to send optical signals through a single fiber in two directions.

ABS Box 3 Ports Fiber Optical Circulator High Reliability / Stability With SC Connector
