1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC
1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC
1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC
1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC
Specifications
Brand Name :
GEZHI or OEM
Model Number :
GZ-1x1-13/15
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
50000pcs per month
Delivery Time :
2-7 work days
Packaging Details :
2pcs in a foam with plastic Box
Product Name :
1x1 Optical Switches
Control Type :
Non-Latching/Latching
Wavelength :
1260~1650nm
Voltage :
5V or 3V
Feature :
High Reliability
Connector :
FC/APC-LC/UPC or customized
Operating temperature: :
-20~70℃
Description

1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC

1x1 Optical Switches

1x1 Mechanical Optical Switch is used to turn on and turn off optical signal. The 1x1 Mechanical Optical Switch is based on Advanced Optoelectronic Integrated Technology. With the development of optical communication, Optical Switch device is the key to a new generation of all-optical network in near future.

Features

Highly Stable & Reliable
Short switching time
Compact design, Miniature size
Low Insertion Loss
Wide operating wavelength Range
Fail-Safe Latching and Non-latching
Single mode or Multimode optional

Applications

System Monitor
Configurable OADM
Metropolitan Area Network
R&D in Laboratory

Specification

item
value
Model Number
1X1-switch
Type
Other
Place of Origin
China
Manufacturer Location
Shenzhen
Brand Name
OEM
Use
FTTH
Warranty Time
1year
Network
Wireless Lan, wifi, 4g
Type
Testers &Tools
Use
FTTH
Product name
1x1 optical switch
Application
Telecommunication
Type
1X1
Color
Customized
Wavelength
1310/1550nm
Warranty
1 Year
No. of Fiber
2

Pins

Type Optical Route Electric Drive State Sensor
1×1 Pin 1 Pin 5 Pin 6 Pin 10 Pin 2-3 Pin 3-4 Pin 7-8 Pin 8-9
Non-Latching CUT -- -- -- -- Close Open Open Close
P1-P2 V＋ -- -- GND Open Close Close Open
Latching CUT -- -- GND -- Close Open Open Close
P1-P2 V＋ GND -- -- Open Close Close Open


Order Information

GZ-1×1-13/15

Mode Wavelength Voltage Type Control Model Fiber Type Fiber Diameter Fiber Length Connector
S=SM
M=MM		 85=850nm
13=1310nm
15=1550nm
13/15=1310/1550nm
X=Others		 3=3V
5=5V		 L=Latching
N=Non- Latching		 5=50/125
6=62.5/125
9=9/125
X=Others		 25=250um
90=900um
20=2.0mm
30=3.0mm
X=Others		 1=1m
2=1.5m
X=Others

0=None
FP=FC/PC
FA=FC/APC
SP=SC/PC
SA=SC/APC
LP=LC/PC
LA=LC/APC

X=Others

Optical Route

1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC

1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC

Mechanical Drawing

1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC

Our Certificates

1625/1650nm Mechanical Optical Switch Low Crosstalk 1x1 FC APC

FAQ

Q1:Who are we?
A1:We are based in Shenzhen, China, start from 2011,sell to Domestic Market(42.00%),South Asia(18.00%),South America(15.00%),Southeast Asia(12.00%),Eastern Europe(10.00%),North America(3.00%). There are total about 50-100 people in our office.
Q2: How can we guarantee quality?
A2: Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q3: What can you buy from us?
A3: Fiber Optic Products,FTTH Products,PLC Splitter,Fiber Optic Patch Cord,WDM Series,FTTH Box,Fast Connector,Fiber Switch
Q4: What services can we provide?
A4: Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DES；
Accepted Payment Currency:USD,JPY,GBP,CNY;
Accepted Payment Type: T/T,D/P D/A,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,German,French,Italian
