4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic
Specifications
Place of Origin :
JIANGSU, CHINA
Brand Name :
TONGDA
Packaging Details :
PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
Supply Ability :
800sets/year
Price :
$37,999.00 - $44,999.00/Sets
Certification :
CE, ISO9001
MOQ :
1SET
Delivery Time :
28 working days
Payment Terms :
T/T, L/C, D/P, West Union
Model Number :
TONGDA HTll5L
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
PLC, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Plastic Processed :
PP, HDPE, PC, ABS, PVC, PE, EVA, PA, ABS/PP, PE/PP, HDPE/PP, PETG
Year :
2020
Voltage :
Customized to customer needs
Dimension(L*W*H) :
3.43m*2.3m*2.65m
Hollow part volume :
1-5L
Clamping Force (kN) :
70
PLC Brand :
MITSUBISHI
Screw L/D Ratio :
25
Screw diameter (mm) :
70 mm
Output (kg/h) :
85 kg/h
Automation :
Automatic
No. of Screw Heating Zone :
4
Screw Heating Power(kW) :
19 kW
Extruder Motor Power(kW) :
30 kW
Mold Platen Size(Width)(mm) :
480 mm
Mold Platen Size(Height)(mm) :
450 mm
Air Pressure(MPa) :
0.6 MPa
Air Comsumption(m³/min) :
0.8 m³/min
Die Head Heating Power(kW) :
10.7 kW
Accumulator Capacity(L) :
0 L
Power (kW) :
53.8
Weight (T) :
5.5
Key Selling Points :
Long Service Life
Warranty :
1 Year
Applicable Industries :
Energy & Mining, Hotels, Home Use, Machinery Repair Shops, Restaurant, Food & Beverage Factory, Farms
Showroom Location :
Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria
Rotary Cylinder Brand :
FESTO
Station :
Double Station
Suitable bottle :
1-5L
Key words :
Automatic Extrusion Blow Moulding Machine
Packing :
Wooden
Use :
Hollow Moulding
Parison Control :
MOOG
Max. Size of Mold :
390*390
Hydraulic valve :
Yuken
Color :
Blue
Port :
shanghai
Description

TONGDA HTll5L Fully automatic 4l 5l detergent bottle hollow blow molding machine

Product Description

This is our basic series machine.It is double station.This machine is suitable for producing 50ml-20L plastic containers.Most cost effective series machine for high production capacity choice.

Technical Parameters

MODEL Units HTII-2L Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume L 5
Output of HDPE kg/h 85
Clamping force kn 70
Screw diametre mm 70
Screw heating power kw 13.2
Blow pressure mpa 0.6
Size of machine m 3.43*2.3*2.65

Product Details

Standard air valve, with stable function

4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic

Large touch screen, equipped with Japanese moog 100 poinst Parison control, simpler operation and more perfect products

4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic

Company Information

"Working Together to Grow Together" is the spirit of Suzhou Tongda Machinery, to cooperate with us and we are always at your service to provide you with strong support.

4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic

4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic

After-sales services

During epidemic period, our team have helped customers start up more than 250sets new Tongda machines by online service, to help customer run the machine as soon, our after sales team helped around 3 hours till the mid-night.

4L 5L Hollow Detergent Bottle Blow Molding Machine Fully Automatic

FAQ

Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of auxiliary equipment.
5. A free 2-day training course will be provided to customers every year.
6. Special processing equipment to produce after-sales accessories to ensure rapid response to user needs.


Q: How big is your company?
A: our company has 400 employees and A building area of 100,000 square meters. We own land and factories.The company has a registered capital of us $2 million and a long-term business license since 1999.


Q: How long is the warranty on your equipment?
A: we offer A one-year free warranty and A lifetime after-sales service.
