Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN
Specifications
Brand Name :
TONGDA
Model Number :
TDB-120F
Certification :
CE, ISO9001
Place of Origin :
JIANGSU, CHINA
MOQ :
1SET
Price :
USD 94,499~99,999 per set
Payment Terms :
T/T, L/C, D/P, West Union
Supply Ability :
800sets/year
Delivery Time :
28 working days
Packaging Details :
PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
Screw Diametre :
100mm
Screw length/diameter ratio :
25
Output of HDPE :
180 kg/hour
Clamping force :
740KN
Platen distance :
500-1400mm
Max.Size of Mold :
900*1450mm
Air consumption :
1.6m3/min
Water consumption :
180 L/min
Description

TONGDA TDB-120F 120L Open Top Chemical Drum Multi Layer Extrusion Blow Moulding Plastic Container Blow Molding Machine

Product Description

Our TDB-120F model extrusion blow molding machine is with wide applications. Not only suitable for producing plastic big barrel, open top containers, such as 50L-120L open top single ring chemical drums, also are suitable for extrusion molding diffent usage plastic hollow products, such as medical bed board, hollow rescue stretcher, plastic female mannequin half body and full body, table sheet, desk board, etc.

Equipped with servo motor not only for hydraulic system, also the extruder, so it will save 10-30% energy.

Our efficient plasticizing mixing screw, which ensures the plastic is fully and evenly plasticized, then improve product surface quality and effectively prevent screw temperature rise.

Technical Parameters

MODEL Units TDB-120F Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume L 120
Output of HDPE kg/h 180
Clamping force kn 740
Screw diametre mm 100 25:1
Screw heating power kw 21
Blow pressure mpa 0.6
Size of machine m 5.8×2.9×4.3

Product Details

Hydraulic system: proportional pressure control, equipped with famous brand hydraulic components, which are stable and reliable.

Excellent flow channel technology and precise machining accuracy, make the color change and material change more efficient. From dark to white, normally can be completed within 3hours. Much quicker than other suppliers. Save cost for you if you need to produce different color products.

Company Information

Suzhou Tongda Machinery Co., Ltd., located in Zhangjiagang City, 2 hours away from Shanghai City by car.

The factory covers an area of more than 80 acres of land and has more than 350 employees.

From negotiation to determining the optimal production plan for customers, from equipment installation and commissioning, maintenance, system operation to production process, we provide you with reasonable suggestions and perfect solutions at each stage, as well as fast spare parts supply and convenience. technical service and support.

Open Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kNOpen Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kNOpen Top Chemical Drum Multi Layer Blow Moulding Machine 120L 740 kN

Service Marketing Network

  • Over 7000sets Tongda machines are serving customers all over the world
  • Having service office in Russia, Egypt, Jordan, Thailand, Chile, Indonesia and Algeria
  • We are not only providing our customers with high quality products, but also provide high quality service Which will be rapidly and timely sent to every customer.

Advantages of TONGDA after-sales team

  • Lifetime free service for the machine.
  • Quick response all day long.
  • Set up domestic service team and international service team.
