High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle
Specifications
Brand Name :
TONGDA
Model Number :
TONGDA HTS
Certification :
CE, ISO9001
Place of Origin :
JIANGSU, CHINA
MOQ :
1SET
Price :
$29,999.00/Sets >=1 Sets
Payment Terms :
T/T, L/C, D/P, West Union
Supply Ability :
800sets/year
Delivery Time :
28 working days
Packaging Details :
PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
PLC, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Plastic Processed :
PP, HDPE, PC, ABS, PVC, PE, EVA, PA, ABS/PP, PE/PP, HDPE/PP, PETG
Year :
2020
Voltage :
Customized to customer needs
Dimension(L*W*H) :
2.78m*1.55m*2.35m
Hollow part volume :
1-2L
Clamping Force (kN) :
44
PLC Brand :
MITSUBISHI
Screw L/D Ratio :
25
Screw diameter (mm) :
50 mm
Output (kg/h) :
50 kg/h
Automation :
Automatic
No. of Screw Heating Zone :
3
Screw Heating Power(kW) :
6.8 kW
Extruder Motor Power(kW) :
11 kW
Mold Platen Size(Width)(mm) :
300 mm
Mold Platen Size(Height)(mm) :
320 mm
Air Pressure(MPa) :
0.6 MPa
Air Comsumption(m³/min) :
0.4 m³/min
Die Head Heating Power(kW) :
7 kW
Accumulator Capacity(L) :
0 L
Power (kW) :
30.5
Weight (T) :
4
Key Selling Points :
Long Service Life
Warranty :
1 Year
Applicable Industries :
Energy & Mining, Hotels, Home Use, Machinery Repair Shops, Restaurant, Food & Beverage Factory, Farms
Showroom Location :
Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria
Rotary Cylinder Brand :
FESTO
Station :
single
Suitable bottle :
1-2L
Key words :
Automatic Extrusion Blow Moulding Machine
Packing :
Wooden
Use :
Hollow Moulding
Parison Control :
MOOG
Max. Size of Mold :
360*320
Hydraulic valve :
Yuken
Product name :
Automatic Blowing Molding Machine
Port :
shanghai
Description

Automatic High Speed Blow Molding Machine 2L Plastic Bottle Manufacturer Machine

Product Description

This machine is suitable for the small bottles.The main parts of this machine are designed and manufactured by ourself.E.g:ly chemical vegetable wash fruit cleaning /cream lotion cosmetic bottle

Technical Parameters

MODEL Units HTS-2L Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume L 5
Output of HDPE kg/h 50
Clamping force kn 44
Screw diametre mm 50
Screw heating power kw 6.8
Blow pressure mpa 0.6
Size of machine m 2.78*1.55*2.35

Product Details

Parison controller we use MOOG 200 Points or AUTOMATA 300 Points, with extremely sensitive action.
Touch screen we use large size INNOVANCE

High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle

Stable and efficient clamping system

Adjustable rotary type blow pin unit, suitable for oblique bottles

High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle

Company Information

Suzhou Tongda Machinery have more than 20,000m2 factory buildings and other facilicities and a new intelligent manufacturing factory with 55,000m2 area. The I phase 20,000m2 area factory will be put into use in June, 2022. And on May 19th, 2022, we just held the II phase intelligent manufacturing base groundbreaking ceremony.

High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle

After-sales services

During epidemic period, our team have helped customers start up more than 250sets new Tongda machines by online service, to help customer run the machine as soon, our after sales team helped around 3 hours till the mid-night.

High Speed Automatic Blow Molding Machine 11 KW 2L Plastic Bottle

FAQ

TONGDA sales consultant
1. We can provide comprehensive and professional Suggestions on equipment selection.
2. Energy consumption calculation and investment income analysis can be provided.
3. Provide tailor-made CAD drawings of workshop layout and product optimization Suggestions.
4. Extrusion plastic bottle blow molding machine has remote maintenance function

Q: How big is your company?
A: our company has 400 employees and A building area of 100,000 square meters. We own land and factories.The company has a registered capital of us $2 million and a long-term business license since 1999.


Q: How long is the warranty on your equipment?
A: we offer A one-year free warranty and A lifetime after-sales service.
