FTP Ethernet Patch Cable With Shielding Cat 7 LAN 24AWG Gauge LSZH

Product Description

Features

1. 23AWG/24AWG Solid Copper Core

2. Diameter of Conductor : 0.58/0.56/0.51/0.50/0.48/0.45/0.40mm 7*0.2mm /7*0.18mm/ 7*0.16mm

3. PVC or LSZH

4. FTP (shielded Twisted Pair)

5. Strictly comply with the international standard.

6. The length and color of the jacket can be assigned by the customer.

Application

• The wires are intended for voice, text, data, video, and image transmission.
• 10 GBASE-T ETHERNET
• 10 BASE-T, 100 BASE-T FAST ETHERNET
• 100 VG-AnyLAN, 155/622 Mbps ATM
• 550 MHz Broadband Video
• Their transmission characteristics are specified for frequencies up to 600MHz.

Specification

1) CONDUCTOR

Raw material of the conductor: solid bare copper

Conductor Dia.: 0.585±0.03mm (23AWG)

2) INSULATION

Raw material of the conductor: F-PE

Quantity:4 twisted pairs

Color:Blue/white-blue; Green/white-green; Orange/white-green

Insulation Diameter : 1.45±0.05mm

Average thickness: 0.432mm

Minimum point thickness: 0.4mm

3) TWISTED PAIRS SCREEN

Aluminum foil

4) OVERALL SCREEN

Raw material of the screen: 96/0.10mm TC wire braiding

Coverage rate:≥40%

5) JACKET RIP CORD

Nylon thread

6) SHEATH

Sheath material: LSZH or PVC

Nominal Dia.: 7.5 ± 0.2mm

Average thickness: 0.65mm

Minimum point thickness: 0.55mm

Mechanical Properties

Conductor insulation material: halogen free Foam/Skin material

Cable jacket material: halogen-free, flame-retardant material

Application area: dray as well as humid rooms

Temperature (moved): 0°C to 50°C

Operating temperature: -20°C to +60°C

Min. bending radius for one-time bending: 4×O.D.

Min. bending radius during installation: 8×O.D.

Electrical properties

Loop impendence: 130 W/km

Highest impendence difference: 2%

Insulation resistance >5000 MW x km

Impendence Z0 at 1 500MHz: 100 W ± 15%

Impendence Z0 at 1 350MHz: 100 W ± 18%

Surface transfer impendence: < 100 MW per Meter at 10MHz

Earthing symmetry db/BZL = 1000m > 46dB at 64kHz

Earthing symmetry db/BZL = 100m > 40dB at 1MHz

Earthing symmetry db/BZL = 100m > 20dB at 100MHz

Mutual capacitance: 43pF/m

Highest earthing-coupling: 0,001MHz: 1000 pF/km

Propagation speed at > 10MHz (NVP*c): 0,79c

Signal propagation delay >10MHz: 4,2ns/m
