Cold Rolled Steel Communication Rack Cabinet / Electronic Equipment Cabinet YH9003
Cold Rolled Steel Communication Rack Cabinet / Electronic Equipment Cabinet YH9003
Specifications
Brand Name :
YUHUI
Model Number :
Sun protection Windproof Proof Communication Rack Cabinet with Flexible Size YH12
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
10
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000 per week
Delivery Time :
10 work days
Packaging Details :
cartons and PU box
status :
new and stock both
style and brand :
as customer
test or sample :
anytime we do
original :
Ningbo,zhejiang
material :
cold rolled steel
advantage :
Sun protection Windproof Proof
Description

Sun protection Windproof Proof Communication Rack Cabinet with Flexible Size YH9003

The interior of the cabinet shall be provided with 4 or 6 mounting columns for the installation of equipment and fixed floor plates. The installation column can be moved forward and backward to adjust;
The internal dimensions of the cabinet, such as spacing and hole spacing of the installation columns, shall meet the requirements of GB/T 3047.2;
The depth of the laminate is 850mm±5mm, and the load of the reinforced laminate is ≥100kg. Each laminate requires 15 laminates.
Laminates should be easy to install and remove, and their installation height and front and rear positions can be adjusted;
The fixing method of the laminating board can be fixed according to the user's needs, using screws or elastic bolts, snap-in parts, etc.;
The effective installation depth of equipment inside the cabinet is ≥950mm;
The cabinet is designed with upper cabling. Three lower holes are provided on both sides of the top of the rack. Rubber protection is applied around the holes to prevent abrasion and avoid sharp edges damaging the cables. Power lines and signal lines go through separate outlet holes
