product size:360*90*15mm
display size:350*60mm
pixel:12*72 dots
Input Voltage:DC 5-12V
Power:4W
Color: Red, white, blue, yellow selectable.
Pixel Pitch | 5mm | |
LED Model | SMD2020 | |
Pixel Configuration | R, G, B color | |
Module size(W×H) | 160mm*160mm | |
Module resolution(W×H) | 12*72 | |
Cabinet resolution(W×H) | 192*96 | |
Module configuration(W×H) | 2×2 | |
Cabinet Size(W×H×D) | 360*90*15mm | |
Weight | 5.8Kg/cabinet;48.3Kg/m2 | |
Cabinet Material | Aluminum | |
Installation Type | Fixed installation | |
(5)Display Parameter | ||
Density | 160,000pixels/m2 | |
Brightness | 600cd/m2~1200cd/m2 Adjustable | |
View angle | 160°/160° | |
View distance | 2.5m~50m | |
Flatness | ≤0.2mm | |
Wavelength tolerance | <3% | |
Brightness uniformity | ≥97% | |
Chroma uniformity | ±0.003 within Cx Cy | |
Contrast | 3000:1 | |
Ingress Protection(F/R) | IP20/IP41 | |
Application | Indoor | |
(6)Control System | ||
Grayscale level | 14bit | |
Drive Mode | Constant current | |
Scan Mode | 1/16 | |
Refresh Rate | ≥2000Hz | |
Frame | 50/60Hz | |
Color Temperature | 3000K~9500K Adjustable | |
Brightness control mode | Manual/Auto/Remote control | |
Calibration | Brightness calibration Color calibration | |
Control Type | Manual/Auto/Remote control | |
Control distance | <100m | Cat 5E Net cable |
100m~500m | Multimode fiber | |
500m~10Km | Single mode fiber | |
Input signal | AV/S-Video/VGA/DVI/ HDMI/SDI/DP | |
Software Interface | Windows XP/7/8 | |
(7)Operation parameter | ||
Max. power consumption | ≤650W/m2 | |
Ave. power consumption | 180W/m2~240W/m2 | |
Working voltage | AC: 100V~240V(50/60 Hz) | |
Signal to noise ratio | ≥47 | |
Malfunction dot rate | ≤3×10-4 | |
MTBF | ≥10000 hours | |
LEDLifetime | 100,000 hrs (typical), 50% brightness | |
Operating temperature | -10℃~40℃ | |
Operating humidity | 10%~90%RH |
1. May I know the Minimum order for your products:
For the modules or cabinet, it is ok to order 1 pcs for sample.
2. What's the difference of DIP(1R1G1B) and DIP(One LED, 3 in 1) ?
DIP(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led chips in one LED Lamp;
Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.
2.1.DIP(One LED), reduced the LED on the screens, it reduced grainy of the screen, and improve the uniform of the screen, this will make the screen have a more wide viewing angle and smooth image.
2.2. Keeps the high brightness for outdoor advertising.
Because it adopted advanced technology of DIP and SMD, so it can keep the high brightness of the screen. Much high brightness than SMD Screens.
3. How long time I can get the cargos?
Our production time is about 12-20 working days;
When we confirmed the order, after we get your deposit, we can start production, we will update the production details in time; Before finish, we will notice you and after we get full payment, we can delivery the goods to you.
About the time from start port to destination, that depends on the distance and the state of the sea company or airport company.
4. May I know the package details?
For our product, generally we can provide you package by Plywood case or Flight case.
Generally speaking, for outdoor fixed, we use plywood case, 2 cabinets in one case; For rental market, we suggest you use flight case, generally 6 or 8 cabinets in one case.
For this P2.5 indoor full color LED display Screen for HD image and video commercial advertising, we suggest you use plywood case, it's safe to protect the screen on the way, also economical.
5. Besides this product, may I have other options?
Yes, my dear friend. Many thanks for finish the details of this product, if this not you're looking for, you can also choose other items, we have P2.5-P10 HD indoor led display, p4.81-p25 full color for outdoor; Different cabinet, Steel Cabinet, Aluminum Cabinet, Die Cast Aluminum Cabinet, etc; The pixel pitch is from 1.5mm to 50mm. We also have different transparent led display, triangle led display, dj booth, led curtain, flexible led display, LED advertising player and kinds of video processor.
For more information, please contact me now! We will reply you within 12 hours.
