4mm led wall for stage background design screen

Specifications

Application :

Indoor, indoor

Color :

Full color

Panel Size :

256*128mm

Supplier Type :

original manufacturer, ODM

Media Available :


Place of Origin :

Guangdong, China

Model Number :

GTKI040

Brand Name :

GTEAK

use :

advertising publish, shopping mall, exhibition hall, education

Function :

SDK

Pixel Pitch :

4mm, 4mm

Specification :

Video Wall

Tube Chip Color :

FULL COLOR

Display Function :

Video

Power Supply :

Meanwell etc

Keyword :

led wall for stage background design

Item :

4mm led wall for stage background design

Product name :

4mm led wall for stage background design screen

Pixel configuration :

SMD 1R1G1B

Cabinet material :

die-casting aluminum

Pixels :

4mm

Port :

Shenzhen

Price :

$750.00/square meters 1-99 square meters

Description

4mm led wall for stage background design screen

Product Description

4mm led wall for stage background design screen

Parameter		GTKI040
Basic Parameter	Pixel Configuration	SMD 3 in 1
	Pixel Pitch (mm)	4.0mm
	Pixel Density	62,500 Pixels/SQM
	Module Dimensions (L×W)/(mm)	256mm*256mm
	Cabinet Dimension(WHD)	512mm * 512mm
	Cabinet Weight (kg/sqm)	50kg
Optical Parameter	Color Grayscale (bit)	14bit
	Frame Frequency (Hz)	50/60Hz
	Brightness (nit)	2,000 cd/m2
	Viewing angle	140°/140°
	Flatness error	≤0.5mm
Using Parameter	Working Voltage (V)	AC: 100-240V(50/60 Hz)
	Max. Power Consumption	220 W/cabinet
	Storage Temperature (°C)	-20~60
	Operating Temperature (°C)	-10~40
	Storage Humidity (RH)	10%~90%
	Operating Humidity (RH)	10%~90%
	IP Rating (Front / Rear)	IP43
	Lifetime Typical Value (hrs)	50,000

4mm led wall for stage background design screen

FAQ

1. How to choose the led display most suitable for my project? And what is the best price you can offer?

First of all, you’d better to know the application of the screen ( Indoor or Outdoor); the size of the screen would be ( Length & Height); what will the screen will be used for ( advertising, on live event, need to be installed somewhere permanently or for rental use). We will check out the best price and screen upon your conditions

2. What is your lead time?

Under the normal condition, sample order for 3-7 working days, regarding mass order, if we have available raw material,the lead time will around 15 working days, otherwise, would be 20-30 working days

3. What is your payment method?

Our usually practice for payment is by T/T for the mass order and also we do the trade assurance ( Provided by Alibaba and Gteak to make sure your payment, shipment, goods’ quality security and ensurance)

4. What is your shipping and packing way?

Our standard packing for modules are carton box and for the led cabinet, we do wood box or flight case as per customers’ requests. For the mass order ( fit for a container), we do shipment by Sea and for others usually by express or airlin

5. Can i place a sample order before i decide to do the mass production?

Yes, we acceptable sample orders, please let us know your detail request then we will send you the sample asap for confirmatio

6. Can i have a free sample?

We offer free sample for some models, please advise what you need to see if we have available free samples here to be sent

4mm led wall for stage background design screen

Name: 4mm led wall for stage background design screen
Brand: GTEAK
Price: 750.00 USD
