12v Micro PM Brushed DC Motor Planetary Geared High Torque Low Rpm DC Motor 80Rpm
12v Micro PM Brushed DC Motor Planetary Geared High Torque Low Rpm DC Motor 80Rpm
Specifications
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 piece/pieces per month
Type :
Small planetary gear motor with Motor
Torque :
50kg.cm
Speed :
80Rpm
Protect Feature :
Totally Enclosed
Application :
Home Applicance
Feature :
High Efficiency
Description

12v Micro PM DC Brushless Planetary Geared Motor High Torque And Low Rpm Dc Motor

A brushless DC motor (known as BLDC) is a permanent magnet synchronous electric motor which is driven by direct current (DC) electricity and it accomplishes electronically controlled commutation system (commutation is the process of producing rotational torque in the motor by changing phase currents through it at appropriate times) instead of a mechanically commutation system. BLDC motors are also referred as trapezoidal permanent magnet motors.

1. Standard Operating Conditions:
1-1 Rated Voltage:
24V DC constant between motor terminals
1-2 Direction of Rotation:
CW when viewed from output shaft side
1-3 Operating Temperature and Humidity
Temperature range of -10℃~+50℃, Humidity range of 30%~80% temperature range of -10℃~+50℃
1-4 Storage Temperature
Temperature range of -20℃~+60℃
2.Measuring Conditions:
2-1 Motor Position:
To be place t horizontally when measuring
2-2 Power Supply:
Regulated DC power supply
2-3 Environmental Temperature and Humidity:
Temperature range of 15℃ to 30℃
Relative humidity 30%and 70%
2-4Power Sopply
Regulated DC power supply
--No load speed:1600rpm. 1200rpm 430RPM 230RPM 130RPM 120RPM 85RPM 60RPM 45RPM 32RPM 23RPM 16RPM 12RPM 8RPM
2-5 Application:
--Robotics, Small Appliance, Fanner, Electric Curtain;
--Medical Pump, Surgery Tools, Medical Stirrer, centrifugal Machine; Electric Valve, Actuator, medical device
--Electric motor,low noise,low current and no spark.
--Robotics, Small Appliance, Fanner, Electric Curtain;
--Medical Pump, Surgery Tools, Medical Stirrer, centrifugal Valve, Actuator, medical device
2-6 Character:
--Electric motor,low noise,low current and no spark.
--High quantity ,small body
--Gear Ratio : 3.7 5.18 14 27 50 71 100 139 189 263 369 516 721
--- 3650 brushless DC motor : 24v 6000R 12V 6000R 24v8000R

Product Description

  • Product Name: Brushless DC Motor
  • Number of Phase: 3 Phase
  • Number of Poles: 4 Poles /8 Poles /10 Poles
  • Rated Voltage: 24v /36v /48v /310v
  • Rated Speed: 3000rpm /4000rpm /or customized
  • Rated Torque: Customized
  • Rated Current: Customized
  • Rated Power: 23w~2500W

Customized spares parts

1) voltage, current, speed and torque.

2) Shape of shaft: "D" "Round" "Flat" "Hexagon Axis" "Square axis".

3) Bearing: ball bearing.

4) Materials of shell: plastic and metal.

5) Tooth form: Spur gear,helical gear.

Company Introduction

Changzhou paliwei Motor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.

Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.
