8mm Shaft Dc Brushed 120 Watts Brushed DC Motor With Speed Reducer Controller
8mm Shaft Dc Brushed 120 Watts Brushed DC Motor With Speed Reducer Controller
Specifications
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 piece/pieces per month
Torque :
0.05-0.44N.m
Speed :
1000-8000rpm
Shaft diameter :
8mm
Continuous Current(A) :
customized
Protect Feature :
Totally Enclosed
Application :
Home Applicance
Feature :
High Efficiency
Description

Dc Brushed 120watts Brushed DC Motor Motor With Speed Reducer Controller

A DC motor or direct current motor is an electrical machine that transforms electrical energy into mechanical energy by creating a magnetic field that is powered by direct current. When a DC motor is powered, a magnetic field is created in its stator. The field attracts and repels magnets on the rotor; this causes the rotor to rotate. To keep the rotor continually rotating, the commutator that is attached to brushes connected to the power source supply current to the motors wire windings.

One of the reasons DC motors are preferred over other types of motors is their ability to precision control their speed, which is a necessity for industrial machinery. DC motors are able to immediately start, stop, and reverse—an essential factor for controlling the operation of production equipment.

Brushless DC motors have a permanent magnet rotor and a coil wound stator. This design of DC motor removes the need for brushes. The benefit of a brushless DC motor is the elimination of wear and tear of brushes since very little heat is produced by the rotating magnet. The efficiency of brushless DC motors makes them more expensive.

Number of Poles 4
Number of Phases 3
Nominal Voltage VDC 24
Rated speed RPM 2500 3000 3000 3000 3000 3000
Continuous Torque N-m 0.057 0.11 0.165 0.22 0.33 0.44
Output Power Watts 15 34 52 69 103 138
Peak Torque1 N-m 0.18 0.38 0.58 0.8 1.2 1.6
Peak Current Amps 2.7 6.8 10.0 13.2 19.8 25.8
Line to line Resistance Ohms 3.6 1.2 0.9 0.65 0.5 0.35
Line to line Inductance mH 2.6 2.2 1.3 1.1 0.6 0.5
Torque constant N-m/Amps 0.074 0.059 0.06 0.062 0.062 0.063
Back EMF V/kRPM 7.75 6.2 6.3 6.5 6.5 6.6
Rotor inertia g·cm2 32 42 58 72 106 140
Body Length (L) mm 37 47 57 67 87 107
Mass kg 0.43 0.5 0.67 0.75 1.0

1.25

Product Description

  • Product Name: Brushless DC Motor
  • Number of Phase: 3 Phase
  • Number of Poles: 4 Poles /8 Poles /10 Poles
  • Rated Voltage: 24v /36v /48v /310v
  • Rated Speed: 3000rpm /4000rpm /or customized
  • Rated Torque: Customized
  • Rated Current: Customized
  • Rated Power: 23w~2500W

Company Introduction

Changzhou paliwei Motor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.

Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.
