DC high power Brushless motor,32mm diameter 70mm length,12V24V36V,8000-10000rpm
DC high power Brushless motor,32mm diameter 70mm length,12V24V36V,8000-10000rpm
Specifications
Brand Name :
ASSUN
Model Number :
AM-BL3270BF-1208
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1-10pcs
Price :
Negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300000/Month
Delivery Time :
5-15 work days
Packaging Details :
Cartonbox
Nominal voltage :
12V
No load speed ±12% :
8426 rpm
No load current Max *150% :
750mA
Max cont.torque :
125.8 mN.m
Rated Speed :
7653 rpm
Rated current :
10000mA
Rated Power :
100.83W
Starting current :
109091 mA
Maximum Efficiency :
84.1%
Stall Torque :
11484 mN.m
Terminal resistance ±12% :
0.11 Ω
Weight :
280.1g
Description

Product Description:

DC high power Brushless motor,32mm diameter 70mm length,12V24V36V,8000-10000rpm

Product introduction:

1.High power DC Brushless Motor,8000-10000rpm.36V24V12V.length 70mm.diameter 32mm.

2. No load speed ±12%: 8426rpm. No load current Max150%:750mA .Maximum power output 327.3W. Terminal resistance ±12%: 0.11Ω.

3.Torque constant 13.6mN.m/A. Speed constant 702rpm/V, Speed / torque gradient 5.7rpm/ V.

4. High temperature DC Coreless motors can install the corresponding with encoder and planetarty gearbox.

5. Weight :280.1g. Motor thermal resistance : 7.0K/W.Maximum winding temperature: 155℃,Ambient temperatue range : -30 to 66℃.

Product Details:

Motor Model AM-BL3270BF-1208 Unit
Nominal voltage 12 V
No load speed ±12% 8426 rpm
No load current Max150% 750 mA
Max cont.torque 125.8 mN.m
Rated Speed 7653 rpm
Rated Current 10000 mA
Rated Power 100.83 W
Starting current 109091 mA
Stall Torque 11484 mN.m
Maximum power output 327.3 W
Maximum Efficiency 84.1 %
Terminal resistance ±12% 0.11 Ω
Motor thermal resistance 7.0 K/W
Mechanical time constant 1.12 ms
Moment of inertia 18.91 gcm²
Torque constant 13.6 mN.m / A
Speed constant 702 rpm / V
Speed / torque gradient 5.7 rpm / mN.m
Weight 280.1 g

DC high power Brushless motor,32mm diameter 70mm length,12V24V36V,8000-10000rpm

DC high power Brushless motor,32mm diameter 70mm length,12V24V36V,8000-10000rpm

Application :

DC high power Brushless motor,32mm diameter 70mm length,12V24V36V,8000-10000rpm

Motor data tested at 25℃.Motor operation exceeding continuous limits will reduce life or result in damage.

At elevated ambient temperature.load current must be reduced.

Service idea :

We can search for qualified products according to the required specifications (size, torque, revolutions, etc.) of gearbox, DC motor and reducer proposed by customers. The products searched are just one example of a rich product lineup, and there are many products that have not been published. At the same time, we also undertake special product design and OEM development. For relevant matters, please contact the business department of our company.

More information. please vist our website : www.assunmotor.com
