P6 P8 P10 Stage LED Video Wall Rental Full Color High Resolution LED Display RGB
P6 P8 P10 Stage LED Video Wall Rental Full Color High Resolution LED Display RGB
Specifications
Brand Name :
DDW
Model Number :
DDW-IFCP6000
Certification :
CE/ROHS/FCC/UL/ISO/3C
Place of Origin :
Shenzhen ,China
MOQ :
Negotiable
Payment Terms :
Bank T/T transfer, Western Union
Supply Ability :
6000sqm/month
Delivery Time :
7-20 days
Packaging Details :
Plywood or Flight Case
Price :
Negotiable
Protection Leve :
IP65
Led Chip :
Epistar/Slian
RGB :
2R1G1B / 1R1G1B
Aspect ratio :
6:5
Pixel pitch :
6mm
Panel brightness :
2000nit
Description


P6 P8 P10 Stage LED Video Wall Rental Full Color High Resolution LED Display RGB

>> Specifications

· Pixel Configuration: SMD 1R1G1B
· Pixel Pitch: 6mm
· Module Resolution: 32 × 32 pixel dots
· Module size: 192mm x 192mm
· Cabinet Size: 960 x 960 x 170(mm)

· Cabinet Weight: 35kg

>> Features

· White Balance: D50 to D93

· Extremely Thin Design
· Brightness: 2000nits(adjustable)

· 1R1G1B SMD Pixel Configuration
· Max Power Consumption:15W
· High Viewing Angle

· DC 5V Voltage Input
· High Refresh Rate Performance

Parameter Unit Value
Pixel pitch mm 6
Panel brightness nit 2000
Viewing angle - Horizontal deg. 140
Viewing angle - Vertical deg. 140
Cabinet Weight kg 19
Cabinet Width mm 1024
Cabinet height mm 768
Cabinet depth mm 185
Cabinet area sq. m. 0.79
Cabinet material Aluminium
Aspect ratio 6:5
Ingress Protection (Front/Rear) IP IP65/IP21
Operating temperature range deg. C -20 to 50
Operating Humidity range HR 10% to 90%
Pixel type and configuration R/G/B 1,1,1
Pixel pitch mm 10.667
Pixel matrix per cabinet 96*72
Pixels per cabinet 6912
Lines per meter 94
Pixels per sq. meter 8789
LEDs per sq. meter 26367
Recommended minimum viewing distance m 11
Colours 1.07Billion
Gray scale Levels 1024 levels per colour
Brightness control Levels 100
Digital processing bit 10
Frame rate Hertz 60
Display refresh rate Hertz ≥400
Scan mode Static
Input voltage VAC 110 to 240
Input power frequency Hertz 50 or 60
Input power (max/avg) Watts per sq.m 600/250


>> Characteristics for RGB Led Display
· easily upgrade size of sign.

· user friendly computer system .
· approximate 3D image quality.

· Fast and easy to assemble and dismantle.

· Wide viewing angle ,excellent white color balance.
· High grayscale with perfect visual performance.

· High reliability and long lifespan over 100,000hrs.
P6 P8 P10 Stage LED Video Wall Rental Full Color High Resolution LED Display RGB
