Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121
Specifications
Brand Name :
DDW
Model Number :
OES6
Certification :
CE,ROHS
Place of Origin :
CHINA
MOQ :
1square meter
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 sqm per month
Delivery Time :
7-20 days
Application :
Indoor Advertising
Panel Size :
500*500/500*1000mm
Certificate :
CE ROHS CCC FCC ISO9001
Product name :
P3.91 indoor LED module
Brightness :
1500
LED chip :
San'an
Description

Stage Hanging P3.91 1500nits Rental Led Video Wall SMD2121

MC Series led screen, which contains P1.9, P2.84, P3.9, can be used as indoor fixed led display. It can show exquisite and excellent images, can be both front and back serviceable. Besides, MC series is safe and stable, convenient and cost-effective. It is definitely your wise and worry-free choice.

1.Wireless and Modular Design, Safe and Reliable

Display, receiver and driver are integrated, simplified the internal structure. The connector of power and signal is modular design, using pin header, connected with the driving board directly. Inside of the cabinet is wireless, which has greatly improved the stability and security. Furthermore, the Fire Resistance rate of cabinet is V-0 Grade.

2.Effectively Reduce the Electromagnetic Radiation , Excellent Displays

The EMC certified cabinet with unique circuit and program design is adopted,the signal interference and system electromagnetic radiation is reduced effectively, the showing effect is more stable and worry-free.

Module Parameter:

Pixel pitch 3.91mm
Pixel configuration 1R1G1B
LED type 3-in-1 SMD2121
Module size 250x250mm
Module resolution 64x64dots
Module quantity per cabinet 4pcs


Cabinet Parameter:

Cabinet size 500x500mm
Cabinet material die- casting aluminum
Cabinet weight 6.5kg
Cabinet resolution 128x128 dots
Ingress protection Front/Rear IP65/IP54


Whole Screen Parameter

Pixel density 65410dots/m²
Brightness ≥1200 cd/m²
Viewing angle H≥120° V≥120°
Min.viewing distance 3.9m
Max.power consumption 850W/m²
Avg.power consumption 280 W/m²
Working voltage 110~220VAC±15%
Interface HUB75
Colors 16.7millon colors
Gray level 65536
Refresh rate ≥1920Hz
MTBF ≥100,000 hours
Lifespan ≥100,000 hours
Operating temperature -10℃ ~ +60℃
Storage temperature -20℃ ~ +60℃


Control System Parameter:

Video signal (with video processor) AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature Adjustable by software
Brightness level 256 levels, automatic adjustment by software
Control way Computer, video-synchronous, real-time, off-line, internet etc.
