P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage
P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage
P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage
P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage
Specifications
Brand Name :
DDW
Model Number :
DDW-IRTP5000
Certification :
CE/ROHS/FCC/UL/ISO/3C
Place of Origin :
Shenzhen ,China
MOQ :
Negotiable
Payment Terms :
Bank T/T transfer, Western Union
Supply Ability :
6000sqm/month
Delivery Time :
7-20 days
Packaging Details :
Plywood or Flight Case
Price :
Negotiable
Usage :
Indoor
Brightness :
≥3500cd/m2
Viewing Distance  :
5 - 15 meters
Pixel Pitch :
5mm
Weight :
30Kg
Pixel configuration :
1R1G1B
Description


P5 Indoor LED Video Wall Rental Adjustable Brightness For Events / Theater Stage

Indoor Rental LED Display Screen could be used in indoor environment such as municipal mansion, enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD
encapsulation technology, its purpose is to play the important news or events or TV program .

1) High and adjustable brightness can meet the demands of the changing requirement of Customer in different environments.
2) No mosaic due to excellent flatness and nice uniformity of light-emitting.
3) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change largely in the range.
4) High density make the images softer and vivider.
5) Single-lamp maintenance with low cost.
6) Good heat dissipation capability because of the unique design of vent fan (liking shutter).
7) Environmental-friendly and energy-saving.

Pixel Information Pixel Pitch 5mm
Pixel Density 40000 Pixels/m2
Pixel Configuration 1R1G1B
LED Wavelength Red: 615 nm - 635 nm
Green: 520 nm - 535 nm
Blue: 465 nm - 475 nm
LED Module Module Size(mm) 160 (Width) × 160 (Height)
Module Resolution 32(Width) × 32 (Height)
Cabinet Cabinet Size(mm) 640 (Width) ×640(Height)
Cabinet Resolution 128 (Width) × 128 (Height)
Total QYT Module Per Cabinet 4 (Width) ×4(Height)
Cabinet Weight 30kg/m2
Cabinet Material Die-casting Aluminum LED Display
Power Input Voltage 100-240V AC, 50/60Hz
Max Power Consumption 1100 Watt/m2
Avg. Power Consumption 650 Watt/m2
Brightness ≥3500cd/m2
Brightness Uniformity Luminance Discrepancy < 5%
Best Viewing Angle Horizontal:140°,Vertical:70°
Viewing Distance 5 - 15 meters
Ambint Conditions Temperature Range Working:-20deg. to +60deg
Operating Humidity 10%90%RH
Ingression Protection Grade IP30
Processing Scanning Mode 1/8 scanning
Refresh Frequency 600-1200HZ, Adjustable(depends on control system)
Signal Input DVI, Composite Video for Live Video
Supported Networking Through LAN/WAN, RS 232/RS485
Controller Linsn or Nova

Advantage

· 1. Wide application: it can be used for any rental application of stage show: such as main rental led display, side screen, floor screen, arc screen stage design etc.
· 2. Easy and Fast: for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
· 3. High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.

· 4. Both indoor and outdoor series are compatible, outdoor SMD and DIP screen with IP65 weatherproof level, so it can be used normally in rainy days.

· 5. Floor led screen can bear 1 ton weight, IP65 weatherproof level.
